CPD-G500
– 4 –
TIMING SPECIFICATION
MODE AT PRODUCTION MODE 1 MODE 2 MODE 3 MODE 4
RESOLUTION 1600 X 1200 1920 X 1440 1800 X 1440 1800 X 1350
CLOCK 229.500 MHz 297.000 MHz 299.436 MHz 300.000 MHz
— HORIZONTAL —
H-FREQ 106.250 kHz 112.500 kHz 120.740 kHz 120.968 kHz
usec usec usec usec
H. TOTAL 9.412 8.889 8.282 8.267
H. BLK 2.440 2.424 2.271 2.267
H. FP 0.279 0.485 0.668 0.480
H. SYNC 0.837 0.754 0.481 0.667
H. BP 1.325 1.185 1.122 1.120
H. ACTIV 6.972 6.465 6.011 6.000
— VERTICAL —
V. FREQ(HZ) 85.000 Hz 75.000 Hz 80.120 Hz 85.009 Hz
lines lines lines lines
V. TOTAL 1250 1500 1507 1423
V. BLK 50 60 67 73
V. FP 1111
V. SYNC 3333
V. BP 46 56 63 69
V. ACTIV 1200 1440 1440 1350
— SYNC —
INT(G) NO NO NO NO
EXT(H/V)/POLARITY YES P/P YES P/P YES P/P YES P/P
EXT(CS) /POLARITY NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT
99.07.02 VER.
