Sony Trinitron KV-24FV12 - Transformers, Thermistors, Tuners, Varistors, CB Board, Capacitors

— 58 —
KV-24FV12/25FV12/25FV12A/25FV12C
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading
and mark are critical for safety. Replace
only with part number specified.
TRANSFORMER
T501 1-437-195-11 TRANSFORMER, HORIZONTAL DRIVE
T503 1-426-981-11 TRANSFORMER, FERRITE (PMT)
T504 1-431-693-11 TRANSFORMER, HORIZONTAL LINEAR
T505 1-453-336-11 FBT ASSY NX-4011//X
T602 1-426-717-11 TRANSFORMER, LINE FILTER (LFT)
(KV-24FV12 ONLY)
T602 1-435-617-11 TRANSFORMER, LINE FILTER
(ALL EXCEPT KV-24FV12)
T603 1-433-806-11 TRANSFORMER, REGULATOR
(KV-24FV12 ONLY)
T603 1-433-807-11 TRANSFORMER, REGULATOR
(ALL EXCEPT KV-24FV12)
T604 1-431-852-11 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
TH601 1-803-586-11 THERMISTOR, NTC
THERMISTOR
THP601 1-809-539-11 THERMISTOR, POSITIVE
(KV-24FV12 ONLY)
THP601 1-803-540-11 THERMISTOR
(ALL EXCEPT KV-24FV12)
TUNER
TU101 8-598-431-30 TUNER, FSS BTF-WA411
VARISTOR
VDR601 1-803-585-11 VARISTOR ENE271D-10A
(KV-24FV12 ONLY)
VDR601 1-803-967-11 VARISTOR (ENE621D-14A)
(ALL EXCEPT KV-24FV12)
* A-1332-057-A CB (VAR) MOUNTED PC BOARD
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C701 1-104-664-11 ELECT 47µF 20% 25V
C702 1-136-165-00 MYLAR 0.1µF 5% 50V
C703 1-104-664-11 ELECT 47µF 20% 25V
C704 1-107-649-11 ELECT 2.2µF 20% 250V
C705 1-107-652-11 ELECT 10µF 20% 250V
R646 1-249-419-11 CARBON 1.5K 5% 1/4W
R648 1-215-908-21 METAL OXIDE 33 5% 3W
R649 1-249-417-11 CARBON 1K 5% 1/4W
R650 1-216-387-11 METAL OXIDE 0.68 5% 3W
R651 1-249-429-11 CARBON 10K 5% 1/4W
R653 1-216-049-91 RES-CHIP 1K 5% 1/10W
R655 1-216-049-91 RES-CHIP 1K 5% 1/10W
R656 1-249-429-11 CARBON 10K 5% 1/4W
R658 1-216-387-11 METAL OXIDE 0.68 5% 3W
R659 1-215-857-11 METAL OXIDE 10 5% 1W
R660 1-215-924-00 METAL OXIDE 15K 5% 3W
(KV-24FV12 ONLY)
R660 1-216-485-11 METAL OXIDE 5.6K 5% 3W
(ALL EXCEPT KV-24FV12)
R661 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R662 1-216-485-11 METAL OXIDE 5.6K 5% 3W
(ALL EXCEPT KV-24FV12)
R663 1-216-081-00 RES-CHIP 22K 5% 1/10W
R2001 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R2002 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R2003 1-249-425-11 CARBON 4.7K 5% 1/4W
R2004 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R2006 1-216-295-91 SHORT
(KV-25FV12A ONLY)
R2007 1-249-413-11 CARBON 470 5% 1/4W
(KV-25FV12A ONLY)
R2011 1-249-415-11 CARBON 680 5% 1/4W
R2012 1-249-416-11 CARBON 820 5% 1/4W
R2013 1-249-421-11 CARBON 2.2K 5% 1/4W
R2014 1-249-427-11 CARBON 6.8K 5% 1/4W
RELAY
RY601 1-755-198-11 RELAY
RY602 1-755-266-11 RELAY, AC POWER
SWITCH
S2001 1-692-431-21 SWITCH, TACTILE
S2002 1-692-431-21 SWITCH, TACTILE
S2003 1-692-431-21 SWITCH, TACTILE
S2004 1-692-431-21 SWITCH, TACTILE
S2005 1-692-431-21 SWITCH, TACTILE
S2006 1-692-431-21 SWITCH, TACTILE
S2007 1-762-816-11 SWITCH, TACTILE
S2008 1-762-816-11 SWITCH, TACTILE
SWITCH
SW502 1-572-707-11 SWITCH, LEVER
