— 59 —
KV-24FV12/25FV12/25FV12A/25FV12C
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading
and mark are critical for safety. Replace
only with part number specified.
C707 1-162-114-00 CERAMIC 0.0047µF 2KV
C708 1-136-165-00 MYLAR 0.1µF 5% 50V
C709 1-126-934-11 ELECT 220µF 20% 16V
C710 1-126-964-11 ELECT 10µF 20% 50V
CONNECTOR
CN701 * 1-564-506-11 PLUG, CONNECTOR 3P
CN702 1-695-915-11 TAB (CONTACT)
CN705 1-564-512-11 PLUG, CONNECTOR 9P
CN706 * 1-564-509-11 PLUG, CONNECTOR 6P
DIODE
D701 8-719-901-83 DIODE 1SS83TD
D702 8-719-901-83 DIODE 1SS83TD
D703 8-719-901-83 DIODE 1SS83TD
D704 8-719-302-43 DIODE RGP10GPKG23
IC
IC701 8-759-803-42 IC LA6500-FA
IC702 8-759-562-43 IC TDA6108JF/N1B
JACK
J701 1-451-470-21 SOCKET, CRT
COIL
L701 1-408-613-31 INDUCTOR 68µH
TRANSISTOR
Q700 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q701 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R700 1-247-863-91 CARBON 22K 5% 1/4W
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-247-815-91 CARBON 220 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-249-421-11 CARBON 2.2K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-381-11 CARBON 1 5% 1/4W
R707 1-249-383-11 CARBON 1.5 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
R711 1-260-099-11 CARBON 1K 5% 1/2W
R712 1-260-099-11 CARBON 1K 5% 1/2W
R713 1-260-099-11 CARBON 1K 5% 1/2W
R714 1-260-087-11 CARBON 100 5% 1/2W
R715 1-260-132-11 CARBON 560K 5% 1/2W
R716 1-260-123-11 CARBON 100K 5% 1/2W
R717 1-216-373-11 METAL OXIDE 2.2 5% 2W
R718 1-216-375-00 METAL OXIDE 3.3 5% 2W
R719 1-215-888-00 METAL OXIDE 220 5% 2W
R720 1-249-421-11 CARBON 2.2K 5% 1/4W
R721 1-249-421-11 CARBON 2.2K 5% 1/4W
VARIABLE RESISTOR
RV701 1-241-656-11 RES, ADJ, METAL FILM 110M
HZ
* A-1372-117-A MOUNTED PWB, HZ
(KV-25FV12A ONLY)
CONNECTOR
CN901 * 1-580-843-11 PIN, CONNECTOR (POWER)
CN902 * 1-580-843-11 PIN, CONNECTOR (POWER)
SWITCH
S901 1-571-433-21 SWITCH, PUSH (AC POWER)
* A-1380-629-A K (VAR) MOUNTED PC BOARD
CAPACITOR
C201 1-126-963-11 ELECT 4.7µF 20% 50V
C202 1-126-963-11 ELECT 4.7µF 20% 50V
C404 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C405 1-163-034-00 CERAMIC CHIP 0.033µF 50V
C406 1-163-011-11 CERAMIC CHIP 0.0015µF 10% 50V
C407 1-164-222-11 CERAMIC CHIP 0.22µF 25V
C408 1-164-222-11 CERAMIC CHIP 0.22µF 25V
C409 1-163-011-11 CERAMIC CHIP 0.0015µF 10% 50V
C410 1-163-034-00 CERAMIC CHIP 0.033µF 50V
C411 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C412 1-163-038-91 CERAMIC CHIP 0.1µF 25V
Z
