Sony Trinitron KV-24FV12 - KMB Boards, Capacitors, Connectors, ICs, Chip Conductors, Resistors

 60 
KV-24FV12/25FV12/25FV12A/25FV12C
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
quepar une piece portant le numero specifie.
The components identified by shading
andmark
are critical for safety. Replace
only with part number specified.
C413 1-126-963-11 ELECT 4.7µF 20% 50V
C414 1-126-963-11 ELECT 4.7µF 20% 50V
C415 1-126-963-11 ELECT 4.7µF 20% 50V
C416 1-126-963-11 ELECT 4.7µF 20% 50V
C417 1-126-963-11 ELECT 4.7µF 20% 50V
C418 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C419 1-164-346-11 CERAMIC CHIP 1µF 16V
C422 1-126-963-11 ELECT 4.7µF 20% 50V
C423 1-126-963-11 ELECT 4.7µF 20% 50V
C424 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C425 1-164-346-11 CERAMIC CHIP 1µF 16V
C426 1-126-960-11 ELECT 1µF 20% 50V
C427 1-126-968-11 ELECT 100µF 20% 50V
C428 1-126-968-11 ELECT 100µF 20% 50V
C429 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C430 1-164-222-11 CERAMIC CHIP 0.22µF 25V
C431 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C432 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C433 1-126-960-11 ELECT 1µF 20% 50V
C434 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C446 1-126-933-11 ELECT 100µF 20% 16V
C447 1-126-961-91 ELECT 2.2µF 20% 50V
C448 1-126-961-91 ELECT 2.2µF 20% 50V
C450 1-126-963-11 ELECT 4.7µF 20% 50V
C451 1-126-963-11 ELECT 4.7µF 20% 50V
C455 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C456 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C457 1-163-034-00 CERAMIC CHIP 0.033µF 50V
C458 1-126-963-11 ELECT 4.7µF 20% 50V
C460 1-126-963-11 ELECT 4.7µF 20% 50V
C475 1-163-038-91 CERAMIC CHIP 0.1µF 25V
CONNECTOR
CN402 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CN450 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
IC
IC403 8-759-658-19 IC NJM2198
IC404 8-759-658-01 IC NJW1130G
CHIP CONDUCTOR
JR402 1-216-295-91 SHORT
JR405 1-216-295-91 SHORT
JR406 1-216-295-91 SHORT
JR420 1-216-295-91 SHORT
JR421 1-216-295-91 SHORT
JR422 1-216-295-91 SHORT
JR423 1-216-295-91 SHORT
JR426 1-216-295-91 SHORT
JR427 1-216-295-91 SHORT
JR428 1-216-295-91 SHORT
JR429 1-216-295-91 SHORT
JR452 1-216-295-91 SHORT
JR474 1-216-295-91 SHORT
JR477 1-216-295-91 SHORT
COIL
L410 1-414-271-11 INDUCTOR 47µH
RESISTOR
R403 1-216-025-91 RES-CHIP 100 5% 1/10W
R404 1-216-025-91 RES-CHIP 100 5% 1/10W
R405 1-216-025-91 RES-CHIP 100 5% 1/10W
R406 1-216-025-91 RES-CHIP 100 5% 1/10W
R407 1-216-025-91 RES-CHIP 100 5% 1/10W
R408 1-216-025-91 RES-CHIP 100 5% 1/10W
R409 1-216-025-91 RES-CHIP 100 5% 1/10W
R410 1-216-025-91 RES-CHIP 100 5% 1/10W
R450 1-216-025-91 RES-CHIP 100 5% 1/10W
R451 1-216-025-91 RES-CHIP 100 5% 1/10W
R452 1-216-073-00 RES-CHIP 10K 5% 1/10W
R455 1-216-025-91 RES-CHIP 100 5% 1/10W
R456 1-216-025-91 RES-CHIP 100 5% 1/10W
R477 1-216-113-91 RES-CHIP 470K 5% 1/10W
R478 1-216-113-91 RES-CHIP 470K 5% 1/10W
R479 1-216-113-91 RES-CHIP 470K 5% 1/10W
R480 1-216-113-91 RES-CHIP 470K 5% 1/10W
* A-1304-193-A MB (VAR) MOUNTED PC BOARD
(ALL EXCEPT KV-25FV12A)
* A-1304-192-A MB (VAR) MOUNTED PC BOARD
(KV-25FV12A ONLY)
CAPACITOR
C1002 1-107-698-11 ELECT 10µF 20% 25V
C1005 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1008 1-126-964-11 ELECT 10µF 20% 50V
C1010 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C1011 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1012 1-126-960-11 ELECT 1µF 20% 50V
C1013 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
