KV-24FV12/25FV12/25FV12A/25FV12C
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
quepar une piece portant le numero specifie.
The components identified by shading
andmark
are critical for safety. Replace
only with part number specified.
C1014 1-130-495-00 MYLAR 0.1µF 5% 50V
C1015 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C1016 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C1018 1-126-960-11 ELECT 1µF 20% 50V
C1019 1-104-664-11 ELECT 47µF 20% 25V
C1020 1-163-013-91 CERAMIC CHIP 2200PF 10% 50V
C1021 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1022 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C1023 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1024 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1026 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1027 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1028 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1029 1-163-013-91 CERAMIC CHIP 2200PF 10% 50V
C1031 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1032 1-163-267-91 CERAMIC CHIP 470PF 5% 50V
C1034 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1035 1-163-267-91 CERAMIC CHIP 470PF 5% 50V
C1041 1-126-935-11 ELECT 470µF 20% 16V
C1042 1-163-013-91 CERAMIC CHIP 2200PF 10% 50V
C1043 1-163-809-91 CERAMIC CHIP 0.047µF 10% 25V
C1048 1-137-194-81 MYLAR 0.47µF 5% 50V
C1049 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C1050 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C1053 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C1054 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1055 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C1056 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1058 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1060 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1066 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1068 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1071 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1072 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1073 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1074 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C1075 1-126-935-11 ELECT 470µF 20% 16V
C1076 1-126-959-11 ELECT 0.47µF 20% 50V
C1077 1-126-964-11 ELECT 10µF 20% 50V
C1099 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1304 1-126-959-11 ELECT 0.47µF 20% 50V
C1305 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1306 1-126-933-11 ELECT 100µF 20% 16V
C1307 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1308 1-126-933-11 ELECT 100µF 20% 16V
C1309 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1310 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1311 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1313 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1315 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1320 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1321 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1322 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1323 1-126-933-11 ELECT 100µF 20% 16V
C1324 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1325 1-163-123-00 CERAMIC CHIP 180PF 5% 50V
C1326 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1327 1-126-933-11 ELECT 100µF 20% 16V
C1328 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C1329 1-163-010-11 CERAMIC CHIP 0.0012µF 10% 50V
C1330 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C1331 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1332 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1334 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1335 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1336 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1339 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1340 1-126-963-11 ELECT 4.7µF 20% 50V
C1341 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1342 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1343 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1344 1-126-935-11 ELECT 470µF 20% 16V
C1345 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1349 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1350 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1351 1-126-963-11 ELECT 4.7µF 20% 50V
C1352 1-104-664-11 ELECT 47µF 20% 25V
C1353 1-126-964-11 ELECT 10µF 20% 50V
C1354 1-126-959-11 ELECT 0.47µF 20% 50V
(ALL EXCEPT KV-25FV12A)
C1354 1-126-957-11 ELECT 0.22UF 20% 50V
(KV-25FV12A ONLY)
C1355 1-126-767-11 ELECT 1000µF 20% 16V
C1356 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
(KV-25FV12A ONLY)
C1356 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
(ALL EXCEPT KV-25FV12A)
C1357 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1358 1-126-963-11 ELECT 4.7µF 20% 50V
C1359 1-126-964-11 ELECT 10µF 20% 50V
C1361 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C1363 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
(KV-25FV12A ONLY)
C1364 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C1365 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
(KV-25FV12A ONLY)
C1366 1-126-964-11 ELECT 10µF 20% 50V
C1367 1-126-964-11 ELECT 10µF 20% 50V
C1375 1-163-034-00 CERAMIC CHIP 0.033µF 50V
