KV-24FV12/25FV12/25FV12A/25FV12C
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
quepar une piece portant le numero specifie.
The components identified by shading
andmark
are critical for safety. Replace
only with part number specified.
C1376 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1377 1-126-960-11 ELECT 1µF 20% 50V
C1378 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1379 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
(KV-25FV12A ONLY)
C1379 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
(ALL EXCEPT KV-25FV12A)
C1380 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C1381 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1382 1-126-964-11 ELECT 10µF 20% 50V
C1385 1-126-964-11 ELECT 10µF 20% 50V
C1386 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1387 1-163-267-91 CERAMIC CHIP 470PF 5% 50V
C1389 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1392 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C1394 1-104-664-11 ELECT 47µF 20% 25V
C1399 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
CONNECTOR
CN1000* 1-564-506-51 PLUG, CONNECTOR 3P
CN1001* 1-564-511-11 PLUG, CONNECTOR 8P
CN1002* 1-560-124-00 PLUG, CONNECTOR (2.5MM) 4P
CN1003 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
CN1004 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
CN1303 1-900-805-12 CONNECTOR ASSY 9P BOARD
DIODE
D1001 8-719-921-44 DIODE MTZJ-T-77-5.1C
D1003 8-719-976-99 DIODE UDZ-TE-17-5.1B
D1005 8-719-109-89 DIODE MTZJ-T-77-5.6C
D1010 8-719-977-22 DIODE UDZ-TE-17-9.1B
D1011 8-719-073-01 DIODE MA111-TX
D1012 8-719-073-01 DIODE MA111-TX
D1013 8-719-977-22 DIODE UDZ-TE-17-9.1B
D1014 8-719-073-01 DIODE MA111-TX
D1301 8-719-914-44 DIODE DAP202K-T-146
D1310 8-719-976-99 DIODE UDZ-TE-17-5.1B
FERRITE BEAD
FB1301 1-412-911-11 FERRITE 0µH
FB1302 1-412-911-11 FERRITE 0µH
FILTER
FL1301 1-239-847-11 FILTER, LOW PASS
FL1302 1-239-847-11 FILTER, LOW PASS
FL1303 1-239-847-11 FILTER, LOW PASS
IC
IC1001 8-759-658-03 IC M37273MF-258SP
IC1002 8-759-353-00 IC NJM2534M(TE2)
IC1003 8-759-527-77 IC M24C16-MN6T
IC1301 8-752-090-40 IC CXA2135S
(KV-25FV12A ONLY)
IC1301 8-752-092-17 IC CXA2131AS
(ALL EXCEPT KV-25FV12A)
IC1302 8-759-655-75 IC TC90A49P
IC1304 8-759-353-00 IC NJM2534M(TE2)
IC1305 8-759-658-02 IC BA3993F
CHIP CONDUCTOR
JR0002 1-216-295-91 SHORT
JR1001 1-216-295-91 SHORT
JR1002 1-216-295-91 SHORT
JR1005 1-216-295-91 SHORT
JR1006 1-216-295-91 SHORT
JR1010 1-216-295-91 SHORT
JR1015 1-216-295-91 SHORT
JR1016 1-216-295-91 SHORT
JR1017 1-216-295-91 SHORT
JR1018 1-216-295-91 SHORT
JR1019 1-216-295-91 SHORT
JR1088 1-216-295-91 SHORT
JR1307 1-216-295-91 SHORT
JR1310 1-216-295-91 SHORT
JR1313 1-216-295-91 SHORT
JR1314 1-216-295-91 SHORT
JR1315 1-216-295-91 SHORT
JR1316 1-216-295-91 SHORT
JR1317 1-216-295-91 SHORT
JR1320 1-216-295-91 SHORT
JR1321 1-216-295-91 SHORT
JR1322 1-216-295-91 SHORT
JR1323 1-216-295-91 SHORT
JR1324 1-216-295-91 SHORT
COIL
L1001 1-414-273-11 INDUCTOR 100µH
L1003 1-414-273-11 INDUCTOR 100µH
L1004 1-408-963-11 INDUCTOR 2.7µH
L1302 1-414-267-11 INDUCTOR 10µH
L1303 1-414-267-11 INDUCTOR 10µH
L1304 1-414-267-11 INDUCTOR 10µH
L1305 1-414-267-11 INDUCTOR 10µH
L1310 1-414-267-11 INDUCTOR 10µH
L1311 1-414-271-11 INDUCTOR 47µH
L1315 1-414-267-11 INDUCTOR 10µH
