KV-27FS120/29FS120/29FA310
KV-27FS120/29FS120/29FA310
69
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
! T585 1-453-310-21 FBT ASSY NX-4521//X4J4
! T601 1-435-617-11 TRANSFORMER, LINE FILTER
! T602 1-435-675-11 TRANSFORMER, STANDBY
(KV-27FS120/29FA310LN/29FS120LN ONLY)
! T602 1-435-676-11 TRANSFORMER, STANDBY
(KV-29FS120LS/29FA310LS ONLY)
! T603 1-439-898-21 CONVERTER TRANSFORMER
(KV-27FS120/29FS120LN/29FS120LS ONLY)
THERMISTOR
! THP501 1-804-313-11 THERMISTOR, PTC
(KV-27FS120/29FA310LN/29FS120LN ONLY)
! THP501 1-803-540-11 THERMISTOR, PTC
(KV-29FS120LS/29FA310LS ONLY)
TUNER
! TU101 8-598-593-50 TUNER, FSS BTF-WA421
VARISTOR
! VDR600 1-810-974-21 VARISTOR
(KV-27FS120/29FA310LN/29FS120LN ONLY)
! VDR600 1-803-967-11 VARISTOR
(KV-29FS120LS/29FA310LS ONLY)
CRYSTAL
X001 1-795-006-21 VIBRATOR, CRYSTAL
X301 1-781-377-21 VIBRATOR, CRYSTAL
CW
* A-1410-925-A CW BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C2751 1-107-652-11 ELECT 10µF 20% 250V
C2752 1-162-114-00 CERAMIC 0.0047µF 2KV
C2753 1-137-528-11 MYLAR 0.1µF 10% 250V
C2754 1-102-074-00 CERAMIC 0.001µF 10% 50V
C2755 1-107-651-11 ELECT 4.7µF 20% 250V
C2774 1-126-960-11 ELECT 1µF 20% 50V
C2775 1-126-935-11 ELECT 470µF 20% 16V
C2777 1-126-963-11 ELECT 4.7µF 20% 50V
C2778 1-126-947-11 ELECT 47µF 20% 35V
C3701 1-126-947-11 ELECT 47µF 20% 35V
C3702 1-136-497-81 FILM 0.1µF 5% 50V
C3703 1-126-947-11 ELECT 47µF 20% 35V
C3708 1-136-497-81 FILM 0.1µF 5% 50V
C3780 1-162-926-11 CERAMIC CHIP 82pF 5% 50V
C3781 1-162-926-11 CERAMIC CHIP 82pF 5% 50V
C3782 1-162-926-11 CERAMIC CHIP 82pF 5% 50V
C3901 1-107-667-11 ELECT 2.2µF 20% 400V
C3902 1-107-364-11 MYLAR 0.01µF 10% 200V
C3903 1-126-935-11 ELECT 470µF 20% 16V
C3904 1-130-471-00 MYLAR 0.001µF 5% 50V
C3905 1-107-364-11 MYLAR 0.01µF 10% 200V
C3906 1-130-471-00 MYLAR 0.001µF 5% 50V
C3907 1-107-638-11 ELECT 33µF 20% 160V
C3908 1-126-935-11 ELECT 470µF 20% 16V
C3909 1-104-999-11 MYLAR 0.1µF 5% 200V
C3910 1-104-999-11 MYLAR 0.1µF 5% 200V
C3911 1-104-665-11 ELECT 100µF 20% 25V
C3912 1-126-935-11 ELECT 470µF 20% 16V
C3913 1-126-933-11 ELECT 100µF 20% 16V
C3914 1-130-491-00 MYLAR 0.047µF 5% 50V
C3915 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3930 1-104-655-91 ELECT 470µF 20% 6.3V
C3931 1-104-655-91 ELECT 470µF 20% 6.3V
CONNECTOR
CN2707 1-564-506-11 PLUG, CONNECTOR 3P
* CN2752 1-564-512-11 PLUG, CONNECTOR 9P
CN2753 1-785-879-11 CONNECTOR, ONE TOUCH
CN2755 1-695-915-11 TAB (CONTACT)
* CN3903 1-564-506-11 PLUG, CONNECTOR 3P
DIODE
D2701 8-719-108-12 DIODE RD9.1EW
D2754 8-719-901-83 DIODE 1SS83
D2755 8-719-901-83 DIODE 1SS83
D2756 8-719-901-83 DIODE 1SS83
D2758 8-719-074-25 DIODE PG104R
D3762 8-719-404-50 DIODE MA111-TX
D3763 8-719-404-50 DIODE MA111-TX
D3772 8-719-404-50 DIODE MA111-TX
A
CW
