Sony Trinitron KV-29FA310 - Page 70

KV-27FS120/29FS120/29FA310
KV-27FS120/29FS120/29FA310
70
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
D3773 8-719-404-50 DIODE MA111-TX
D3782 8-719-404-50 DIODE MA111-TX
D3783 8-719-404-50 DIODE MA111-TX
D3901 8-719-110-86 DIODE RD39ESB
D3902 8-719-110-86 DIODE RD39ESB
D3903 8-719-991-33 DIODE 1SS133T-77
D3905 8-719-510-02 DIODE D1NS4
D3906 8-719-404-50 DIODE MA111-TX
D3907 8-719-404-50 DIODE MA111-TX
D3908 8-719-404-50 DIODE MA111-TX
FERRITE BEAD
FB3700 1-410-397-21 FERRITE 1.1µH
FB3701 1-410-397-21 FERRITE 1.1µH
FB3702 1-410-397-21 FERRITE 1.1µH
FB3703 1-410-397-21 FERRITE 1.1µH
IC
IC2751 8-759-562-43 IC TDA6108JF/N1B
IC3701 8-759-803-42 IC LA6500-FA
JACK
! J2751 1-451-544-11 SOCKET, CRT
CHIP CONDUCTOR
JR3910 1-216-864-11 SHORT CHIP
COIL
L2751 1-408-613-31 INDUCTOR 68µH
L3710 1-410-387-11 INDUCTOR 33µH
L3711 1-410-387-11 INDUCTOR 33µH
L3712 1-410-387-11 INDUCTOR 33µH
L3901 1-412-528-11 INDUCTOR 18µH
TRANSISTOR
Q2772 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3710 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3711 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3712 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3761 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3762 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3763 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3771 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3772 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3773 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3781 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3782 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3783 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3901 8-729-053-87 TRANSISTOR KTC4370A
Q3902 6-550-247-01 TRANSISTOR KTA1659A
Q3903 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3904 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3905 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3906 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3907 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3908 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R2756 1-260-328-11 CARBON 1K 5% 1/2W
R2757 1-260-328-11 CARBON 1K 5% 1/2W
R2758 1-260-328-11 CARBON 1K 5% 1/2W
R2760 1-260-087-11 CARBON 100 5% 1/2W
R2761 1-216-375-00 METAL OXIDE 3.3 5% 2W
R2762 1-216-375-00 METAL OXIDE 3.3 5% 2W
R2763 1-247-807-31 CARBON 100 5% 1/4W
R2764 1-247-807-31 CARBON 100 5% 1/4W
R2765 1-247-807-31 CARBON 100 5% 1/4W
R2766 1-247-807-31 CARBON 100 5% 1/4W
R2767 1-247-807-31 CARBON 100 5% 1/4W
R2768 1-247-807-31 CARBON 100 5% 1/4W
R2770 1-260-132-11 CARBON 560K 5% 1/2W
R2785 1-249-399-11 CARBON 33 5% 1/4W
R2788 1-249-421-11 CARBON 2.2K 5% 1/4W
R2789 1-249-425-11 CARBON 4.7K 5% 1/4W
R3700 1-249-433-11 CARBON 22K 5% 1/4W
R3701 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3702 1-216-813-11 METAL CHIP 220 5% 1/10W
R3704 1-249-419-11 CARBON 1.5K 5% 1/4W
R3705 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3706 1-249-381-11 CARBON 1 5% 1/4W
R3707 1-249-383-11 CARBON 1.5 5% 1/4W
R3710 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3711 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
CW
