KV-27FS120/29FS120/29FA310
KV-27FS120/29FS120/29FA310
71
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
R3712 1-218-690-11 METAL CHIP 820 0.50% 1/10W
R3713 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R3714 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3719 1-215-888-00 METAL OXIDE 220 5% 2W
R3760 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3762 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R3763 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3764 1-218-678-11 METAL CHIP 270 0.50% 1/10W
R3765 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R3766 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R3767 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R3768 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3769 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3770 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3771 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3772 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R3773 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3774 1-218-678-11 METAL CHIP 270 0.50% 1/10W
R3775 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R3776 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R3777 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R3778 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3779 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3780 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3782 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R3783 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3784 1-218-678-11 METAL CHIP 270 0.50% 1/10W
R3785 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R3786 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R3787 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R3788 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3901 1-249-405-11 CARBON 100 5% 1/4W
R3902 1-249-385-11 CARBON 2.2 5% 1/4W
R3903 1-249-414-11 CARBON 560 5% 1/4W
R3904 1-249-432-11 CARBON 18K 5% 1/4W
R3905 1-249-421-11 CARBON 2.2K 5% 1/4W
R3906 1-249-432-11 CARBON 18K 5% 1/4W
R3907 1-249-385-11 CARBON 2.2 5% 1/4W
R3908 1-249-414-11 CARBON 560 5% 1/4W
R3909 1-260-316-51 CARBON 100 5% 1/2W
R3910 1-215-915-11 METAL OXIDE 470 5% 3W
R3911 1-216-812-11 METAL CHIP 180 5% 1/10W
R3912 1-216-811-11 METAL CHIP 150 5% 1/10W
R3913 1-216-806-11 METAL CHIP 56 5% 1/10W
R3914 1-216-820-11 METAL CHIP 820 5% 1/10W
R3915 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3916 1-216-864-11 SHORT CHIP
R3917 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3918 1-216-805-11 METAL CHIP 47 5% 1/10W
R3919 1-216-805-11 METAL CHIP 47 5% 1/10W
R3921 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3922 1-249-397-11 CARBON 22 5% 1/4W
R3923 1-249-401-11 CARBON 47 5% 1/4W
R3930 1-216-864-11 SHORT CHIP
R3931 1-249-421-11 CARBON 2.2K 5% 1/4W
R3932 1-218-696-11 METAL CHIP 1.5K 0.50% 1/10W
R3933 1-216-864-11 SHORT CHIP
R3935 1-249-405-11 CARBON 100 5% 1/4W
R3938 1-216-864-11 SHORT CHIP
VARIABLE RESISTOR
RV2701 1-238-019-11 RES, ADJ, CARBON 47K
! RV2750 1-241-656-11 RES, ADJ, METAL FILM 110M
D
* A-1415-635-A D BOARD, MOUNTED
(ALL EXCEPT KV-29FA310LN/29FA310LS)
! 1-900-807-96 WIRE ASSY, G2 LEAD 180
CAPACITOR
C1815 1-129-718-00 FILM 0.022µF 5% 630V
C1816 1-102-244-00 CERAMIC 220pF 10% 500V
C1817 1-129-709-91 FILM 0.0039µF 5% 630V
C1818 1-164-645-11 CERAMIC 1000pF 10% 500V
C1819 1-102-244-00 CERAMIC 220pF 10% 500V
C1820 1-109-954-11 ELECT 0.47µF 20% 160V
DIODE
D1809 8-719-110-41 DIODE RD15ESB2
D1810 8-719-970-87 DIODE ERA38-06
D1811 8-719-970-87 DIODE ERA38-06
D1812 8-719-081-93 DIODE 1N4937/23
CW
D
