KV-29FS13 / 29FS13C
ADJUSTMENT ITEMS (3 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA NTSC VIDEO RF
AVERAGE
DATA
118 D2GN D2GAIN 0-7 4 5
119 YHCR YHCOR 0-3 0 0
120 YPFC YPFCOR 0-1 0 0
121 SHT SHT 0-3 0 0
122 MVT MVT 0-1 0 0
123 OTT OTT 0-1 0 0
124 CL2D CL2D 0-1 1 1
125 CLKG CLKGGT 0-1 0 0
126 HPLL HPLLFS 0-1 1 1
127 BPLL BPLLFS 0-1 0 0
128 FSCF FSCFG 0-1 0 0
129 PLLS PLLS 0-1 1 1
130 KILR KILR 0-15 3 3
131 HSSL HSSL 0-15 12 12
132 VSSL VSSL 0-15 8 8
133 BGPS BGPS 0-15 4 4
134 BGPW BGPW 0-15 10 10
135 ADCK ADCLKS 0-3 3 3
136 NDSW NSDSW 0-1 1 1
137 PFRN FREE_RUN 0-1 0 0
138 PRVS RVS 0-1 0 0
139 PCON CONTRAST 0-127 97 45
140 PUCO U-DAC 0-127 5 16
141 PVCO V-DAC 0-127 5 24
142 PHUE 0-31 12 15
143 PKIL KILLER 1 0 0
144 PSEP EXT_SC_SEL 0-3 1 2
145 PHIM 0-1 0 0
146 PSUB 0-1 0 0
147 PBGS BG_START 0-63 14 14
148 PDL0 0-15 10 6
149 PDL1 0-15 13 13
150 PBRT Y_OFFSET 0-31 25 25
151 PVP1 0 0
152 PUP1 0 0
153 PVP2 0 0
154 PUP2 0 0
155 PVP3 0 0
156 PUP3 0 0
157 PACS SET_ACC 0-1 1 1
158 PSDL SYNC_DELAY 0-3 2 0
159 PDCO 0-3 2 0
160 PCGA C_GAIN 0-1 1 1
161 PAAF 0-1 0 0
162 PSU2 0-1 0 0
163 PCVF 0-1 0 0
164 PBIT BITSEL 0-1 0 0
165 PAFC AFCBITSEL 0-1 0 0
166 PACC ACC_LEVEL 0-63 21 22
167 PBUR BURST_CLK 0-1 0 0
168 PEVE EVENUPRA 0-1 0 0
169 PINW INV_WFF 0-1 0 0
