ā€” 8 ā€”
KV-29FS13 / 29FS13C
Chassis Assembly
Claw
1-1. REAR COVER REMOVAL
1-2. CHASSIS ASSEMBLY REMOVAL 1-3. SERVICE POSITION
SECTION 1: DISASSEMBLY
3 Screws +BVTP 4x16
CA Board
A Board
3 Screws +BVTP 4x16
3 Screws +BVTP 4x16
5 Screws +BVTP 3x12
VA Board
MA Board
D Board
