— 67 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
* J205 1-817-461-11 PIN JACK BLOCK 5P
* J206 1-817-461-11 PIN JACK BLOCK 5P
J207 1-794-116-11 JACK BLOCK, PIN 2P
CHIP CONDUCTOR
JR2 1-216-864-11 SHORT CHIP
JR4 1-216-864-11 SHORT CHIP
JR9 1-216-864-11 SHORT CHIP
JR10 1-216-864-11 SHORT CHIP
JR12 1-216-864-11 SHORT CHIP
JR13 1-216-864-11 SHORT CHIP
JR14 1-216-864-11 SHORT CHIP
JR15 1-216-864-11 SHORT CHIP
JR33 1-216-864-11 SHORT CHIP
JR202 1-216-864-11 SHORT CHIP
JR205 1-216-864-11 SHORT CHIP
JR206 1-216-864-11 SHORT CHIP
JR301 1-216-864-11 SHORT CHIP
JR302 1-216-864-11 SHORT CHIP
JR303 1-216-864-11 SHORT CHIP
JR304 1-216-864-11 SHORT CHIP
JR305 1-216-864-11 SHORT CHIP
JR306 1-216-864-11 SHORT CHIP
JR307 1-216-864-11 SHORT CHIP
JR308 1-216-864-11 SHORT CHIP
JR309 1-216-864-11 SHORT CHIP
JR311 1-216-864-11 SHORT CHIP
JR312 1-216-864-11 SHORT CHIP
JR313 1-216-864-11 SHORT CHIP
JR321 1-216-864-11 SHORT CHIP
JR322 1-216-864-11 SHORT CHIP
JR323 1-216-864-11 SHORT CHIP
JR324 1-216-864-11 SHORT CHIP
JR330 1-216-864-11 SHORT CHIP
JR331 1-216-864-11 SHORT CHIP
JR333 1-216-864-11 SHORT CHIP
JR336 1-216-864-11 SHORT CHIP
JR337 1-216-864-11 SHORT CHIP
JR403 1-216-864-11 SHORT CHIP
JR410 1-216-864-11 SHORT CHIP
JR415 1-216-864-11 SHORT CHIP
JR416 1-216-864-11 SHORT CHIP
JR418 1-216-864-11 SHORT CHIP
JR420 1-216-864-11 SHORT CHIP
JR421 1-216-864-11 SHORT CHIP
JR428 1-216-864-11 SHORT CHIP
JR440 1-216-864-11 SHORT CHIP
JR442 1-216-864-11 SHORT CHIP
JR500 1-216-864-11 SHORT CHIP
JR580 1-216-864-11 SHORT CHIP
JR590 1-216-864-11 SHORT CHIP
COIL
L001 1-414-857-11 INDUCTOR 100µH
L002 1-414-857-11 INDUCTOR 100µH
L003 1-414-856-11 INDUCTOR 10µH
L004 1-414-857-11 INDUCTOR 100µH
L009 1-414-857-11 INDUCTOR 100µH
L010 1-414-182-11 INDUCTOR 6.8µH
L300 1-414-857-11 INDUCTOR 100µH
L301 1-414-857-11 INDUCTOR 100µH
L302 1-414-856-11 INDUCTOR 10µH
L303 1-410-478-11 INDUCTOR 47µH
L304 1-410-470-11 INDUCTOR 10µH
L500 1-412-537-31 INDUCTOR 100µH
L501 1-406-677-11 INDUCTOR 10MH
L502 1-412-552-81 INDUCTOR 2.2MH
L503 1-406-677-11 INDUCTOR 10MH
L505 1-406-978-11 INDUCTOR 150µH
(KV-32FV310/36FV310 ONLY)
L505 1-419-714-11 INDUCTOR 100µH
(KV-27FV310/29FV310 ONLY)
L511 1-409-955-11 INDUCTOR 8MH
TRANSISTOR
Q001 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q002 8-729-422-27 TRANSISTOR 2SD601A-Q
Q003 8-729-422-27 TRANSISTOR 2SD601A-Q
Q004 8-729-422-27 TRANSISTOR 2SD601A-Q
Q005 8-729-422-27 TRANSISTOR 2SD601A-Q
Q010 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q110 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q300 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q304 8-729-422-27 TRANSISTOR 2SD601A-Q
Q305 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q307 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q308 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q309 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q314 8-729-422-27 TRANSISTOR 2SD601A-Q
A
