Sony Trinitron KV-29FV310 - Page 75

— 75 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R3572 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3573 1-216-805-11 METAL CHIP 47 5% 1/10W
R3580 1-215-857-71 METAL OXIDE 10 5% 1W
R3582 1-216-817-11 METAL CHIP 470 5% 1/10W
R3588 1-216-818-11 METAL CHIP 560 5% 1/10W
CRYSTAL
X3500 1-767-606-11 VIBRATOR, CRYSTAL
P
* A-1404-846-A P (VAR) BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C100 1-126-968-11 ELECT 100µF 20% 50V
C102 1-126-947-11 ELECT 47µF 20% 35V
C103 1-126-964-11 ELECT 10µF 20% 50V
C104 1-126-967-11 ELECT 47µF 20% 50V
C106 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C107 1-126-960-11 ELECT 1µF 20% 50V
C109 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C110 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C111 1-126-960-11 ELECT 1µF 20% 50V
C3300 1-115-156-11 CERAMIC CHIP 1µF 10V
C3301 1-115-156-11 CERAMIC CHIP 1µF 10V
C3302 1-115-156-11 CERAMIC CHIP 1µF 10V
C3303 1-126-947-11 ELECT 47µF 20% 35V
C3304 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C3305 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3308 1-126-947-11 ELECT 47µF 20% 35V
C3312 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C3313 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C3316 1-126-947-11 ELECT 47µF 20% 35V
C3317 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3318 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3319 1-126-947-11 ELECT 47µF 20% 35V
C3320 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3321 1-113-619-11 CERAMIC CHIP 0.47µF 10V
C3322 1-164-373-11 CERAMIC CHIP 0.033µF 25V
C3323 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C3324 1-162-918-11 CERAMIC CHIP 18pF 5% 50V
C3327 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C3328 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3329 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C3330 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3331 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3332 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3334 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3335 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3336 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3337 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3338 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3339 1-126-965-91 ELECT 22µF 20% 50V
C3340 1-126-947-11 ELECT 47µF 20% 35V
C3341 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3343 1-126-947-11 ELECT 47µF 20% 35V
C3390 1-104-665-11 ELECT 100µF 20% 25V
C3391 1-104-665-11 ELECT 100µF 20% 25V
CONNECTOR
* CN150 1-560-124-00 PLUG, CONNECTOR (2.5MM) 4P
* CN160 1-564-507-11 PLUG, CONNECTOR 4P
CN6600 1-695-915-11 TAB (CONTACT)
DIODE
D103 8-719-404-50 DIODE MA111-TX
D104 8-719-404-50 DIODE MA111-TX
D3301 8-719-404-50 DIODE MA111-TX
D3304 8-719-109-72 DIODE RD3.9ESB2
IC
IC3301 6-701-754-01 IC M65665ASP
IC3390 8-759-701-59 IC NJM78M09FA
CHIP CONDUCTOR
JR001 1-216-864-11 SHORT CHIP
JR002 1-216-864-11 SHORT CHIP
COIL
L150 1-414-857-11 INDUCTOR 100µH
L3300 1-414-267-21 INDUCTOR 10µH
L3301 1-410-682-31 INDUCTOR 470µH
L3302 1-414-267-21 INDUCTOR 10µH
L3303 1-414-267-21 INDUCTOR 10µH
L3390 1-412-525-31 INDUCTOR 10µH
TRANSISTOR
Q151 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q152 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3300 8-729-422-27 TRANSISTOR 2SD601A-Q
BC
P
