Sony Trinitron KV-29FV310 - Page 77

— 77 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C3005 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C3006 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C3007 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C3008 1-126-947-11 ELECT 47µF 20% 35V
C3009 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C3010 1-126-947-11 ELECT 47µF 20% 35V
C3011 1-126-947-11 ELECT 47µF 20% 35V
C3012 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C3013 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C3014 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C3015 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C3019 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C3020 1-126-947-11 ELECT 47µF 20% 35V
C3021 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C3023 1-126-947-11 ELECT 47µF 20% 35V
C3025 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C3026 1-126-947-11 ELECT 47µF 20% 35V
C3027 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C3028 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C3029 1-126-947-11 ELECT 47µF 20% 35V
C3033 1-115-467-11 CERAMIC CHIP 0.22µF 10% 10V
C3034 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C3035 1-115-416-11 CERAMIC CHIP 0.001µF 5% 25V
C3036 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C3037 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3038 1-126-960-11 ELECT 1µF 20% 50V
C3039 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3040 1-126-964-11 ELECT 10µF 20% 50V
C3047 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C3048 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3049 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3050 1-162-907-11 CERAMIC CHIP 2pF 0.25pF 50V
C3051 1-127-965-21 FILM CHIP 0.001µF 5% 50V
C3052 1-127-956-21 FILM CHIP 0.1µF 5% 16V
C3053 1-162-907-11 CERAMIC CHIP 2pF 0.25pF 50V
C3054 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3055 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3056 1-164-217-11 CERAMIC CHIP 150pF 5% 50V
C3057 1-164-217-11 CERAMIC CHIP 150pF 5% 50V
C3058 1-126-947-11 ELECT 47µF 20% 35V
C3059 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3060 1-126-947-11 ELECT 47µF 20% 35V
C3061 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C3062 1-115-416-11 CERAMIC CHIP 0.001µF 5% 25V
C3063 1-126-960-11 ELECT 1µF 20% 50V
C3064 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
DELAY LINE
DL3000 1-234-821-11 Y DELAY LINE
DL3001 1-234-821-11 Y DELAY LINE
FERRITE BEAD
* FB3001 1-469-670-21 FERRITE 0µH
* FB3002 1-469-670-21 FERRITE 0µH
IC
IC3000 8-759-458-18 IC TDA8501T
IC3001 8-759-443-11 IC NJM2283M-TE1
IC3002 8-759-346-81 IC NJM2257M(TE2)
IC3003 6-704-300-01 IC ICS1578
IC3004 8-759-828-44 IC NJM2870F33(TE2)
COIL
L3000 1-469-555-21 INDUCTOR 10µH
L3001 1-469-555-21 INDUCTOR 10µH
L3003 1-469-555-21 INDUCTOR 10µH
L3004 1-469-555-21 INDUCTOR 10µH
L3005 1-469-555-21 INDUCTOR 10µH
L3006 1-469-555-21 INDUCTOR 10µH
TRANSISTOR
Q3000 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3001 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3002 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3003 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3004 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3005 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3006 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3007 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3008 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3009 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3010 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3011 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3012 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3013 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3014 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3015 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3016 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3017 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3018 8-729-422-27 TRANSISTOR 2SD601A-Q
