— 87 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
D629 8-719-110-31 DIODE RD12ESB2
D631 6-500-175-01 DIODE 1E3-TB
D632 6-500-175-01 DIODE 1E3-TB
D640 8-719-404-50 DIODE MA111-TX
D641 8-719-404-50 DIODE MA111-TX
D645 6-500-175-01 DIODE 1E3-TB
D646 8-719-404-50 DIODE MA111-TX
D647 6-500-175-01 DIODE 1E3-TB
D690 8-719-982-13 DIODE MTZJ-27
D1400 8-719-991-33 DIODE 1SS133T-77
D1401 8-719-110-08 DIODE RD8.2ESB2
D1402 1-247-807-31 CARBON 100 5% 1/4W
FUSE
!
F601 1-532-506-51 FUSE 6.3A 250V
(KV-29FV310(S) ONLY)
!
F601 1-576-193-11 FUSE 6.3A 125V
(ALL EXCEPT KV-29FV310[S])
FERRITE BEAD
FB602 1-410-397-21 FERRITE 1.1µH
FB604 1-410-397-21 FERRITE 1.1µH
FB605 1-410-397-21 FERRITE 1.1µH
FB609 1-410-397-21 FERRITE 1.1µH
FB614 1-410-397-21 FERRITE 1.1µH
FB616 1-410-397-21 FERRITE 1.1µH
FB617 1-410-397-21 FERRITE 1.1µH
FB650 1-410-397-21 FERRITE 1.1µH
FB651 1-410-397-21 FERRITE 1.1µH
FB652 1-410-397-21 FERRITE 1.1µH
FB653 1-410-397-21 FERRITE 1.1µH
IC
IC600 8-759-670-30 IC MCZ3001D
!
IC601 8-749-012-13 IC DM-58
IC605 8-759-450-47 IC BA05T
IC609 6-702-873-01 IC NJM2396F09
IC1401 6-704-065-01 IC TFA9844J
IC1402 8-759-689-71 IC NJM2188M-TE2
CHIP CONDUCTOR
JR6 1-216-864-11 SHORT CHIP
JR10 1-216-864-11 SHORT CHIP
JUMPER WIRE
JW1456 8-719-991-33 DIODE 1SS133T-77
COIL
L505 1-412-529-81 INDUCTOR 22µH
L604 1-412-525-31 INDUCTOR 10µH
L605 1-412-519-11 INDUCTOR 3.3µH
L606 1-412-519-11 INDUCTOR 3.3µH
L607 1-412-525-31 INDUCTOR 10µH
L608 1-412-529-81 INDUCTOR 22µH
L1400 1-410-470-11 INDUCTOR 10µH
PHOTO COUPLER
!
PH602 8-749-924-35 PHOTO COUPLER ON3171-R
IC LINK
PS601 1-576-337-21 IC LINK 2.7A 50V
PS1401 1-576-337-21 IC LINK 2.7A 50V
TRANSISTOR
Q509 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q600 8-729-052-32 TRANSISTOR IRFIB7N50A-LF31
Q601 8-729-052-32 TRANSISTOR IRFIB7N50A-LF31
Q605 8-729-140-96 TRANSISTOR 2SD774-34
Q606 8-729-422-27 TRANSISTOR 2SD601A-Q
Q608 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q690 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q691 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q1401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1402 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R534 1-216-833-11 METAL CHIP 10K 5% 1/10W
R535 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R603 1-219-513-11 METAL 4.7M 5% 1/2W
(ALL EXCEPT KV-29FV310[S])
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R606 1-216-833-11 METAL CHIP 10K 5% 1/10W
R607 1-216-833-11 METAL CHIP 10K 5% 1/10W
R608 1-216-833-11 METAL CHIP 10K 5% 1/10W
R609 1-205-998-11 CEMENTED 1 5% 10W
R610 1-216-833-11 METAL CHIP 10K 5% 1/10W
R611 1-216-833-11 METAL CHIP 10K 5% 1/10W
R612 1-260-131-11 CARBON 470K 5% 1/2W
R613 1-216-833-11 METAL CHIP 10K 5% 1/10W
R614 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
!
R615 1-202-933-61 FUSIBLE 0.1 10% 1/2W
GK
To Next Page
