Sony Trinitron KV-29FV310 - Page 89

— 89 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
CAPACITOR
C701 1-126-947-11 ELECT 47µF 20% 35V
C702 1-136-165-00 FILM 0.1µF 5% 50V
C703 1-126-947-11 ELECT 47µF 20% 35V
C704 1-107-652-11 ELECT 10µF 20% 250V
C705 1-107-652-11 ELECT 10µF 20% 250V
C706 1-137-528-11 MYLAR 0.1µF 10% 250V
C707 1-162-114-00 CERAMIC 0.0047µF 2KV
C708 1-104-665-11 ELECT 100µF 20% 25V
C709 1-126-964-11 ELECT 10µF 20% 50V
C710 1-126-964-11 ELECT 10µF 20% 50V
C711 1-102-074-00 CERAMIC 0.001µF 10% 50V
C713 1-126-964-11 ELECT 10µF 20% 50V
C714 1-126-947-11 ELECT 47µF 20% 35V
CONNECTOR
* CN701 1-564-506-11 PLUG, CONNECTOR 3P
CN702 1-695-915-11 TAB (CONTACT)
CN704 1-785-879-11 CONNECTOR, ONE TOUCH
* CN705 1-564-511-11 PLUG, CONNECTOR 8P
* CN706 1-564-510-11 PLUG, CONNECTOR 7P
* CN707 1-508-879-11 BASE POST 4P
(KV-36FV310 ONLY)
DIODE
D701 8-719-901-83 DIODE 1SS83
D702 8-719-901-83 DIODE 1SS83
D703 8-719-901-83 DIODE 1SS83
D704 8-719-074-25 DIODE PG104R
IC
IC701 8-759-803-42 IC LA6500-FA
IC702 8-759-562-43 IC TDA6108JF/N1B
IC703 8-759-701-59 IC NJM78M09FA
JACK
! J701 1-451-470-21 SOCKET, CRT
COIL
L701 1-410-482-31 INDUCTOR 100µH
TRANSISTOR
Q700 8-729-422-27 TRANSISTOR 2SD601A-Q
Q701 8-729-422-27 TRANSISTOR 2SD601A-Q
Q703 8-729-422-27 TRANSISTOR 2SD601A-Q
RESISTOR
R700 1-249-433-11 CARBON 22K 5% 1/4W
R701 1-216-833-11 METAL CHIP 10K 5% 1/10W
R702 1-216-810-11 METAL CHIP 120 5% 1/10W
R703 1-216-809-11 METAL CHIP 100 5% 1/10W
R704 1-249-422-11 CARBON 2.7K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-381-11 CARBON 1 5% 1/4W
R707 1-249-383-11 CARBON 1.5 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
R711 1-260-328-11 CARBON 1K 5% 1/2W
R712 1-260-328-11 CARBON 1K 5% 1/2W
R713 1-260-328-11 CARBON 1K 5% 1/2W
R714 1-260-087-11 CARBON 100 5% 1/2W
R715 1-260-132-11 CARBON 560K 5% 1/2W
R716 1-260-123-11 CARBON 100K 5% 1/2W
R717 1-216-377-11 METAL OXIDE 4.7 5% 2W
(KV-32FV310/36FV310 ONLY)
R717 1-216-395-00 METAL OXIDE 3.3 5% 3W
(KV-27FV310/29FV310 ONLY)
R718 1-216-372-11 METAL OXIDE 1.8 5% 2W
(KV-32FV310/36FV310 ONLY)
R718 1-216-396-11 METAL OXIDE 3.9 5% 3W
(KV-27FV310/29FV310 ONLY)
R719 1-215-888-00 METAL OXIDE 220 5% 2W
R720 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R721 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R722 1-247-807-31 CARBON 100 5% 1/4W
R723 1-247-807-31 CARBON 100 5% 1/4W
R724 1-247-807-31 CARBON 100 5% 1/4W
R725 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R726 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R727 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
VARIABLE RESISTOR
! RV701 1-241-656-11 RES, ADJ, METAL FILM 110M
RV702 1-238-019-11 RES, ADJ, METAL FILM 47K
