95
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
< CONNECTOR >
CN7601 £ *1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
CN7602 £ *1-580-844-11 PIN, CONNECTOR (POWER)
< SWITCH >
S7601 £ 1-571-433-21 SWITCH, PUSH (AC POWER)
4-203-258-01 HOLDER, LED
< CAPACITOR >
C7150 1-126-969-11 ELECT 220UF 20.00% 50V
< CONNECTOR >
CN7150 *1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D7150 8-719-081-56 DIODE L-59SRGC-CC
< IC >
IC7150 8-749-014-59 IC TSOP1740KS1
< RESISTOR >
R7150 1-249-409-11 CARBON 220 5% 1/4W
R7151 1-249-411-11 CARBON 330 5% 1/4W
< CAPACITOR >
C7900 1-101-810-00 CERAMIC 100PF 5.00% 500V
C7901 1-101-810-00 CERAMIC 100PF 5.00% 500V
C7903 1-535-143-61 LEAD,JUMPER (5.0MM)
C7904 1-535-143-61 LEAD,JUMPER (5.0MM)
C7925 1-137-372-11 MYLAR 0.022UF 5.00% 50V
C7926 1-137-372-11 MYLAR 0.022UF 5.00% 50V
< CONNECTOR >
CN7902 *1-564-518-11 PLUG, CONNECTOR 3P
CN7904 *1-564-526-11 PLUG, CONNECTOR 11P
< SOCKET >
J7900 1-779-947-11 TERMINAL BLOCK, S
J7925 1-785-448-11 JACK
< COIL >
L7901 1-535-143-61 LEAD, JUMPER (5.0MM)
L7902 1-535-143-61 LEAD, JUMPER (5.0MM)
L7925 1-414-183-41 INDUCTOR 10UH
L7926 1-414-183-41 INDUCTOR 10UH
< RESISTOR >
R7901 1-249-417-11 CARBON 1K 5% 1/4W
R7902 1-247-895-91 CARBON 470K 5% 1/4W
R7903 1-247-895-91 CARBON 470K 5% 1/4W
R7905 1-249-417-11 CARBON 1K 5% 1/4W
R7910 1-249-429-11 CARBON 10K 5% 1/4W
R7911 1-249-425-11 CARBON 4.7K 5% 1/4W
R7912 1-249-429-11 CARBON 10K 5% 1/4W
R7913 1-249-421-11 CARBON 2.2K 5% 1/4W
R7914 1-249-421-11 CARBON 2.2K 5% 1/4W
R7915 1-249-425-11 CARBON 4.7K 5% 1/4W
< SWITCH >
S7900 1-771-947-11 SWITCH, TACTILE
S7901 1-771-947-11 SWITCH, TACTILE
S7902 1-771-947-11 SWITCH, TACTILE
< CAPACITOR >
C3300 1-126-933-11 ELECT 100UF 20.00% 16V
C3301 1-126-933-11 ELECT 100UF 20.00% 16V
C3302 1-126-933-11 ELECT 100UF 20.00% 16V
C3307 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3308 1-126-964-11 ELECT 10UF 20.00% 50V
C3309 1-126-964-11 ELECT 10UF 20.00% 50V
C3310 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3311 1-126-964-11 ELECT 10UF 20.00% 50V
C3312 1-126-964-11 ELECT 10UF 20.00% 50V
C3313 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C3314 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C3315 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C3316 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3319 1-126-964-11 ELECT 10UF 20.00% 50V
C3320 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3321 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3322 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
*A-1646-217-A H8 Board, Complete
*A-1646-218-A H7 Board, Complete
*A-1620-132-A B2 Board, Complete
*A-1624-089-A F4 Board, Complete
F4 H8 H7 B2
