96
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
C3324 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3325 1-126-964-11 ELECT 10UF 20.00% 50V
C3326 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3327 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3328 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3329 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3330 1-126-964-11 ELECT 10UF 20.00% 50V
C3331 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C3333 1-126-964-11 ELECT 10UF 20.00% 50V
C3335 1-126-964-11 ELECT 10UF 20.00% 50V
C3337 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3339 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C3340 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C3345 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C3346 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C3347 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C3348 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C3351 1-126-964-11 ELECT 10UF 20.00% 50V
C3353 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3354 1-104-664-11 ELECT 47UF 20.00% 16V
C3355 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3356 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3359 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3362 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3363 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
< CONNECTOR >
CN3100 1-695-301-11 CONNECTOR, BOARD TO BOARD 40P
< FILTER >
FL3300 1-233-736-21 FILTER, EMI
FL3301 1-233-736-21 FILTER, EMI
FL3302 1-233-736-21 FILTER, EMI
< IC >
IC3300 8-759-991-41 IC L78L05ACZ-AP
IC3301 8-759-669-75 IC TLC2932IPW-E20
IC3302 8-759-546-03 IC SAA4977H-518
IC3304 8-759-546-72 IC SAA4956TJ-V1-518
< COIL >
L3302 1-412-029-11 INDUCTOR CHIP 10UH
L3303 1-412-029-11 INDUCTOR CHIP 10UH
L3304 1-412-029-11 INDUCTOR CHIP 10UH
L3305 1-412-029-11 INDUCTOR CHIP 10UH
L3306 1-412-029-11 INDUCTOR CHIP 10UH
L3307 1-412-029-11 INDUCTOR CHIP 10UH
L3309 1-412-029-11 INDUCTOR CHIP 10UH
L3313 1-412-029-11 INDUCTOR CHIP 10UH
< TRANSISTOR >
Q3300 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q3303 8-729-216-22 TRANSISTOR 2SA1037K-T-146-R
Q3304 8-729-216-22 TRANSISTOR 2SA1037K-T-146-R
Q3305 8-729-216-22 TRANSISTOR 2SA1037K-T-146-R
< RESISTOR >
R3302 1-216-025-91 RES-CHIP 100 5% 1/10W
R3303 1-216-025-91 RES-CHIP 100 5% 1/10W
R3305 1-216-295-91 SHORT 0
R3306 1-216-295-91 SHORT 0
R3307 1-216-295-91 SHORT 0
R3312 1-216-025-91 RES-CHIP 100 5% 1/10W
R3314 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R3315 1-216-041-00 RES-CHIP 470 5% 1/10W
R3316 1-216-041-00 RES-CHIP 470 5% 1/10W
R3317 1-216-041-00 RES-CHIP 470 5% 1/10W
R3318 1-216-041-00 RES-CHIP 470 5% 1/10W
R3319 1-216-041-00 RES-CHIP 470 5% 1/10W
R3320 1-216-041-00 RES-CHIP 470 5% 1/10W
R3323 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3324 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R3325 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3331 1-216-047-91 RES-CHIP 820 5% 1/10W
R3332 1-216-047-91 RES-CHIP 820 5% 1/10W
R3336 1-216-033-00 RES-CHIP 220 5% 1/10W
R3337 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3338 1-412-006-31 INDUCTOR CHIP 10UH
R3339 1-412-006-31 INDUCTOR CHIP 10UH
R3341 1-216-041-00 RES-CHIP 470 5% 1/10W
R3342 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3343 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3344 1-412-006-31 INDUCTOR CHIP 10UH
R3348 1-216-021-00 RES-CHIP 68 5% 1/10W
R3350 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3360 1-216-025-91 RES-CHIP 100 5% 1/10W
R3361 1-216-025-91 RES-CHIP 100 5% 1/10W
R3364 1-216-295-91 SHORT 0
R3370 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3376 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3377 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3380 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3383 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3384 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
B2
