Sony Trinitron KV-29FX65E - Page 59

97
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R3385 1-216-033-00 RES-CHIP 220 5% 1/10W
R3389 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3390 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3391 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3392 1-216-025-91 RES-CHIP 100 5% 1/10W
R3393 1-216-025-91 RES-CHIP 100 5% 1/10W
R3394 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3395 1-216-049-91 RES-CHIP 1K 5% 1/10W
R3396 1-216-295-91 SHORT 0
R3397 1-216-295-91 SHORT 0
R3398 1-216-049-91 RES-CHIP 1K 5% 1/10W
*4-374-846-01 COVER, CAPACITOR, CAP TYPE
< CAPACITOR >
C7626 £ 1-136-527-12 FILM 0.47UF 20.00% 300V
< CONNECTOR >
CN7611 £ *1-580-843-11 PIN, CONNECTOR (POWER)
CN7622 1-695-915-11 TAB (CONTACT)
CN7633 £ *1-580-843-11 PIN, CONNECTOR (POWER)
CN7655 1-695-915-11 TAB (CONTACT)
< FUSE >
F7626 £ 1-576-232-11 FUSE (H.B.C.) 5A/250V
£ 1-533-725-11 HOLDER, FUSE (F7626)
< RESISTOR >
R7626 £ 1-202-719-00 SOLID 1M 20% 1/2W
R7627 £ 1-220-797-11 CEMENTED 0.47 5% 10W
< TRANSFORMER >
LF7627 £ 1-433-488-11 TRANSFORMER, LINE FILTER
< VARISTOR >
VD7626 £ 1-803-830-11 VARISTOR (ERZV14D621)
4-382-854-11 SCREW (M3X10), P, SW (+)
< CAPACITOR >
C1100 1-104-664-11 ELECT 47UF 20.00% 25V
C1101 1-126-943-11 ELECT 2200UF 20.00% 25V
C1126 1-162-568-11 CERAMIC CHIP 0.33UF 10.00% 16V
C1127 1-136-175-00 FILM 0.68UF 5.00% 50V
C1128 1-163-135-00 CERAMIC CHIP 560PF 5.00% 50V
C1129 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1130 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C1131 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C1132 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C1133 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1134 1-126-961-11 ELECT 2.2UF 20.00% 50V
C1135 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1136 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1137 1-126-953-11 ELECT 2200UF 20.00% 35V
C1138 1-126-953-11 ELECT 2200UF 20.00% 35V
C1140 1-111-216-91 ELECT 150UF 20.00% 63V
C1141 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1142 1-130-777-00 MYLAR 0.1UF 5.00% 63V
C1151 1-162-568-11 CERAMIC CHIP 0.33UF 10.00% 16V
C1152 1-136-175-00 FILM 0.68UF 5.00% 50V
C1153 1-163-135-00 CERAMIC CHIP 560PF 5.00% 50V
C1154 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1155 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C1156 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C1157 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C1158 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1159 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1160 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1162 1-111-216-91 ELECT 150UF 20.00% 63V
C1163 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1164 1-130-777-00 MYLAR 0.1UF 5.00% 63V
C1177 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1178 1-126-964-11 ELECT 10UF 20.00% 50V
C1179 1-126-965-11 ELECT 22UF 20.00% 50V
C1180 1-126-952-11 ELECT 1000UF 20.00% 35V
C1181 1-126-952-11 ELECT 1000UF 20.00% 35V
C1182 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1183 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
*A-1624-086-A F1 Board, Complete
A Board, Common Parts
B2
*A-1632-913-A A Board, Complete
(KV-29FX65B)
*A-1632-912-A A Board, Complete
(KV-29FX65E/29FX65K)
F1 A
