98
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
C1184 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C1226 1-104-661-91 ELECT 330UF 20.00% 16V
C1227 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1326 1-163-059-91 CERAMIC CHIP 0.01UF 10.00% 50V
C1327 1-126-934-11 ELECT 220UF 20.00% 10V
C1328 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C1601 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1602 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1603 1-126-933-11 ELECT 100UF 20.00% 16V
C1604 1-126-933-11 ELECT 100UF 20.00% 16V
C1605 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1607 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1608 1-126-934-11 ELECT 220UF 20.00% 16V
C1610 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1611 1-126-933-11 ELECT 100UF 20.00% 16V
C1612 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1613 1-126-933-91 ELECT 100UF 20.00% 16V
C1615 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C1617 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
< CONNECTOR >
CN1111 *1-564-520-11 PLUG, CONNECTOR 5P
CN1200 1-695-298-11 CONNECTOR, BOARD TO BOARD 40P
CN1401 1-695-298-11 CONNECTOR, BOARD TO BOARD 40P
CN1600 1-900-903-64 CONNECTOR ASSY 20P
CN1601 1-900-903-64 CONNECTOR ASSY 20P
CN1602 1-900-903-64 CONNECTOR ASSY 20P
CN1700 *1-564-507-11 PLUG, CONNECTOR 4P
CN1702 *1-564-506-11 PLUG, CONNECTOR 3P
CN1703 1-764-334-11 PLUG, CONNECTOR 11P
CN1801 1-695-299-11 CONNECTOR, BOARD TO BOARD 50P
CN1802 *1-564-506-11 PLUG, CONNECTOR 3P
CN1901 1-695-298-11 CONNECTOR, BOARD TO BOARD 40P
CN1902 *1-564-507-11 PLUG, CONNECTOR 4P
CN1904 *1-564-506-11 PLUG, CONNECTOR 3P
CN1988 *1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D1100 8-719-914-43 DIODE DAN202K-T-146
D1101 8-719-914-44 DIODE DAP202K-T-146
D1102 8-719-914-43 DIODE DAN202K-T-146
D1103 8-719-914-43 DIODE DAN202K-T-146
D1104 8-719-914-43 DIODE DAN202K-T-146
D1201 8-719-976-96 DIODE UDZ-TE-17-4.7B
D1401 8-719-056-82 DIODE UDZ-TE-17-6.2B
D1402 8-719-056-82 DIODE UDZ-TE-17-6.2B
D1405 8-719-914-44 DIODE DAP202K-T-146
D1406 8-719-914-43 DIODE DAN202K-T-146
D1407 8-719-069-55 DIODE UDZS-TE17-5.6B
D1408 8-719-069-55 DIODE UDZS-TE17-5.6B
D1626 8-719-914-43 DIODE DAN202K-T-146
D1627 8-719-914-43 DIODE DAN202K-T-146
D1629 8-719-914-43 DIODE DAN202K-T-146
< FERRITE BEAD >
FB1126 1-410-397-21 FERRITE 1.1UH
FB1127 1-410-397-21 FERRITE 1.1UH
FB1151 1-410-397-21 FERRITE 1.1UH
FB1152 1-410-397-21 FERRITE 1.1UH
FB1901 1-414-553-11 FERRITE 0UH
FB1903 1-414-553-11 FERRITE 0UH
FB1904 1-414-553-11 FERRITE 0UH
FB1905 1-414-553-11 FERRITE 0UH
FB1906 1-414-553-11 FERRITE 0UH
FB1907 1-414-553-11 FERRITE 0UH
< IC >
IC1126 8-759-544-25 IC TDA7482
IC1151 8-759-544-25 IC TDA7482
IC1176 8-759-333-24 IC LM1876TF
IC1400 8-752-072-94 IC CXA1875AM-T4
IC1601 8-759-069-28 IC PQ05RF11
IC1602 8-759-574-76 IC KA78R05-SYDTU
IC1604 8-759-054-12 IC PQ09RF11
IC1605 8-759-069-28 IC PQ05RF11
< COIL >
L1126 1-416-857-11 INDUCTOR 65UH
L1127 1-414-158-11 INDUCTOR 2.2UH
L1128 1-414-158-11 INDUCTOR 2.2UH
L1151 1-416-857-11 INDUCTOR 65UH
L1152 1-414-158-11 INDUCTOR 2.2UH
L1153 1-414-158-11 INDUCTOR 2.2UH
L1326 1-414-183-41 INDUCTOR 10UH
< TRANSISTOR >
Q1100 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1101 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1201 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1202 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1204 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1226 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1227 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1229 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q1326 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1327 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
A
To Next Page
