Sony Trinitron KV-29FX65E - Page 61

99
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
Q1328 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1329 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1601 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1626 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
< RESISTOR >
JR1203 1-216-296-91 SHORT 0
JR1601 1-216-296-91 SHORT 0
R1001 1-216-295-91 SHORT 0
R1002 1-216-295-91 SHORT 0
R1003 1-216-295-91 SHORT 0
R1004 1-216-295-91 SHORT 0
R1005 1-216-295-91 SHORT 0
R1006 1-216-295-91 SHORT 0
R1100 1-216-025-91 RES-CHIP 100 5% 1/10W
R1101 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1103 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1104 1-216-296-91 SHORT 0
R1126 1-216-631-11 METAL CHIP 150 0.5% 1/10W
R1127 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1128 1-216-041-00 RES-CHIP 470 5% 1/10W
R1151 1-216-631-11 METAL CHIP 150 0.5% 1/10W
R1152 1-216-075-00 RES-CHIP 12K 5% 1/10W
R1153 1-216-041-00 RES-CHIP 470 5% 1/10W
R1176 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R1179 1-216-357-00 METAL OXIDE 4.7 5% 1W
R1180 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1181 1-216-045-00 RES-CHIP 680 5% 1/10W
R1182 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1183 1-216-045-00 RES-CHIP 680 5% 1/10W
R1184 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1185 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1201 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1202 1-216-083-00 RES-CHIP 27K 5% 1/10W
R1203 1-216-083-00 RES-CHIP 27K 5% 1/10W
R1204 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R1205 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1206 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1208 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1209 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1210 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1227 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1228 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1229 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1230 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R1232 1-216-295-91 SHORT 0
R1233 1-216-049-91 RES-CHIP 1K 5% 1/10W
R1326 1-216-025-91 RES-CHIP 100 5% 1/10W
R1327 1-216-025-91 RES-CHIP 100 5% 1/10W
R1328 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1329 1-216-025-91 RES-CHIP 100 5% 1/10W
R1330 1-216-041-00 RES-CHIP 470 5% 1/10W
R1331 1-216-041-00 RES-CHIP 470 5% 1/10W
R1332 1-216-041-00 RES-CHIP 470 5% 1/10W
R1333 1-216-075-00 RES-CHIP 12K 5% 1/10W
R1334 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R1335 1-216-025-91 RES-CHIP 100 5% 1/10W
R1336 1-216-041-00 RES-CHIP 470 5% 1/10W
R1337 1-216-041-00 RES-CHIP 470 5% 1/10W
R1338 1-216-001-00 RES-CHIP 10 5% 1/10W
R1339 1-216-041-00 RES-CHIP 470 5% 1/10W
R1340 1-216-043-91 RES-CHIP 560 5% 1/10W
R1342 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1403 1-216-295-91 SHORT 0
R1404 1-216-295-91 SHORT 0
R1405 1-216-025-91 RES-CHIP 100 5% 1/10W
R1407 1-216-025-91 RES-CHIP 100 5% 1/10W
R1408 1-216-025-91 RES-CHIP 100 5% 1/10W
R1409 1-216-025-91 RES-CHIP 100 5% 1/10W
R1410 1-216-025-91 RES-CHIP 100 5% 1/10W
R1411 1-216-295-91 SHORT 0
R1412 1-216-295-91 SHORT 0
R1601 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1602 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R1603 1-216-025-91 RES-CHIP 100 5% 1/10W
R1605 1-216-049-91 RES-CHIP 1K 5% 1/10W
R1609 1-216-089-91 RES-CHIP 47K 5% 1/10W
R1610 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1616 1-216-304-11 RES-CHIP 3.3 5% 1/10W
R1617 1-216-304-11 RES-CHIP 3.3 5% 1/10W
R1618 1-216-295-91 SHORT 0
R1621 1-216-027-00 RES-CHIP 120 5% 1/10W
R1622 1-216-029-00 RES-CHIP 150 5% 1/10W
R1623 1-216-033-00 RES-CHIP 220 5% 1/10W
R1625 1-216-295-91 SHORT 0
< TUNER >
TU1326 1-693-340-11 TUNER/VIF (KV-29FX65B)
1-693-338-11 TUNER/VIF (KV-29FX65E/29FX65K)
A Board, Variant Parts KV-29FX65B/29FX65E/29FX65K
