10 —
KV-32FV1/34FVL1/36FV1
27
MDP (Multi Disc Player)
code numbers
Manufacturer Code
Sony 701
Panasonic 704, 710
Pioneer 702
Operating an MDP
To turn on or off
To play
To stop
To pause
To scan
To search the
chapter forward or
backward
Tip z
If you will not be programming a DBS or cable box into
the DBS/CABLE function of your remote, you can use it
to program other video equipment (e.g. DVD, MDP, or
second VCR). (see page 26)
DVD (Digital Versatile Disc)
code numbers
Manufacturer Code
Sony 751
Panasonic 753
Pioneer 752
RCA 755
Toshiba 754
Operating a DVD
player
To turn on or off
To play
To stop
To pause
To scan
To search the
chapter forward or
backward
To select chapters
directly
MENU
To move cursor in
menu
Buttons on the remote
control
Press VTR/DVD (POWER).
Press (.
Press p.
Press P.
To resume normal playback,
press again or press (.
Press ) or 0 during
playback.
To resume normal playback,
press (.
Press CH +/–.
0–9 + ENTER.
Press to display DVD menu.
Use your arrow buttons
V, v, B, b.
Buttons on the remote
control
Press VTR/DVD (POWER).
Press (.
Press p.
Press P.
To resume normal playback,
press again or press (.
Press ) or 0 during
playback.
To resume normal playback,
press (.
Press CH +/–.
Tips z
In some rare cases, you may not be able to operate
your non-Sony video equipment with the supplied
remote control. In this case, please use the
equipment’s own remote control.
When you remove the batteries, the code number may
revert to the factory setting.
The code numbers for Sony VCR's are assigned at the
factory as follows:
VHS VCR 301
(preset code for the
supplied remote control)
8 mm VCR 302
Beta, ED Beta VCRs 303
28
Manufacturer
Hamlin/Regal
Jerrold/G. I.
Oak
Panasonic
Pioneer
Scientific Atlanta
Tocom
Zenith
Programming the remote
You can program the supplied remote
control to operate a cable box or DBS
receiver.
1 Press CODE SET.
2 Press DBS/CABLE (FUNCTION).
3 Use the 0-9 buttons to key in the
manufacturer's code number from the
following chart.
4 Press ENTER.
For more details on operating the
cable box or DBS receiver
Refer to the operating instructions that were
supplied with the equipment.
If the remote control doesn’t work
First, try repeating the setup procedures
using the other codes listed for your
equipment.
Tips z
If more than one code number is listed, try
entering them one by one until you come to the
correct code for your equipment.
If you enter a new code number, the code number
you previously entered at that setting is erased.
In some rare cases, you may not be able to operate
your equipment with the supplied remote control.
In this case, use the equipment’s supplied remote
control.
Whenever you remove the batteries the code
numbers may revert to the factory setting.
Cable box code numbers
Code
222, 223, 224, 225, 226
201, 202, 203, 204, 205, 206,
207, 208, 218
227, 228, 229
219, 220, 221
214, 215
209, 210, 211
216, 217
212, 213
DBS receiver code numbers
Manufacturer
Sony
General Electric
Hitachi
Hughes
Panasonic
RCA/PROSCAN
Toshiba
Code
801 (preset code for
remote control)
802
805
804
803
802, 808
806, 807
Operating a Cable Box or DBS Receiver
29
Problem What it could be What you can do
Troubleshooting
Consult the table below; it suggests solutions to specific problems.
You want to restore the TV's
factory settings
A red light keeps flashing on the
TV for more than a few seconds
TV makes a noise when turned
on
Screen is not lit and there is no
sound
Poor or no picture (screen lit),
good sound
Good picture, no sound
No color
Your TV may need service.
This is a normal function of your TV.
Power cord may not be plugged in.
Batteries may not be inserted correctly.
TV/VIDEO setting may be incorrect.
VIDEO menu settings may not be adjusted correctly.
Antenna/cable connections may be faulty.
VIDEO LABEL inputs may be set to WEB. (This label
darkens the screen for ideal WebTV viewing)
Sound may be set to MUTING.
Your TV may be set to SAP.
Speaker may not be set correctly.
Color settings may not be adjusted correctly.
First, turn the TV on. Then while pressing the RESET
button on the remote control, press the POWER button
on the TV. The TV will turn itself off and then back on.
When the TV turns on again, all settings will be reset,
and the Easy Setup Guide will appear.
Call your local Sony service center.
Press TV/VIDEO until you receive a channel.
Readjust your VIDEO menu settings. (see page 21)
Check your VIDEO LABEL settings. (see page 25)
Press MUTING.
Check the MTS setting in the AUDIO menu. (see page 22)
Check your SPEAKER settings. (see page 22)
Adjust the COLOR settings in the VIDEO menu.
(see page 21)
30
CABLE may not be set correctly
in the SET UP menu.
Antenna/cable connections may
not be correct.
TV may be set to AUX mode.
CABLE setting may not be correct
in the SET UP menu.
CABLE setting may not be set
correctly in the SET UP menu.
Volume may not be adjusted on
your cable box.
CHANNEL FIX settings may not
be correct.
Problem What it could be What you can do
If, after reading these operating instructions, you have additional questions related to the use of your
Sony television, please call our Direct Response Center at 1-800-222-SONY (7669)(U.S. residents only)
or (416) 499-SONY (7669)(customers in Canada only).
Ensure that you have selected the
correct CABLE mode in the SET
UP menu. (see page 24)
Press ANT on your remote
control to change the input mode.
(see page 16)
Ensure that CABLE is set to OFF
in the SET UP menu. (see page 24)
Use AUTO PROGRAM to add
receivable channels that are not
presently in TV memory. (see
page 24)
Ensure that CABLE is set to ON
in the SET UP menu. (see page 24)
Use AUTO PROGRAM to add
receivable channels that are not
presently in TV memory. (see
page 24)
Press TV (FUNCTION) and
adjust the TV's volume.
Check your CHANNEL FIX
settings. (see page 24)
Only snow and noise
appear on the screen
Cannot receive upper
channels (UHF) when
using an antenna
Cannot receive any
channels when using
cable
Cannot gain enough
volume when using a
cable box
TV is fixed to one
channel
Troubleshooting (continued)
