Sony TRINITRON KV-32FV1 - SECTION 8 ELECTRICAL PARTS LIST; Electrical Parts List: Capacitors & Connectors

— 61 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
KV-32FV1/34FVL1/36FV1
SECTION 8
ELECTRICAL PARTS LIST
RESISTORS
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF = µF
INDUCTORS
• UH = µH, MMH = mH
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
Note:
Les composants identifies per un trame
et une marque
¡¡
¡¡
¡ sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
• Items marked " * " are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
REF.NO. PART NO. DESCRIPTION REMARK
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
A
* A-1298-640-A A BOARD, COMPLETE
1-923-084-02 WIRE UL1007 AWG26 60MM BLK
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C001 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C003 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C005 1-126-960-11 ELECT 1MF 20% 50V
C009 1-104-664-11 ELECT 47MF 20% 25V
C010 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C012 1-163-010-11 CERAMIC CHIP 0.0012MF 10% 50V
C013 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C014 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C023 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C028 1-163-227-11 CERAMIC CHIP 10PF 5% 50V
C029 1-163-227-11 CERAMIC CHIP 10PF 5% 50V
C030 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C035 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C036 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C037 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C038 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C039 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C040 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C051 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C053 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C056 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C061 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C062 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C063 1-126-941-11 ELECT 470MF 20% 25V
C071 1-164-096-11 CERAMIC CHIP 0.01MF 50V
C072 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C075 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C351 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C352 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C353 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C354 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C355 1-126-959-11 ELECT 0.47MF 20% 50V
C356 1-126-963-11 ELECT 4.7MF 20% 50V
C357 1-126-959-11 ELECT 0.47MF 20% 50V
C358 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C359 1-104-665-11 ELECT 100MF 20% 25V
C360 1-126-959-11 ELECT 0.47MF 20% 50V
C361 1-126-959-11 ELECT 0.47MF 20% 50V
C362 1-126-959-11 ELECT 0.47MF 20% 50V
C363 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C364 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C365 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C366 1-130-495-00 FILM 0.1MF 5% 50V
C367 1-130-495-00 FILM 0.1MF 5% 50V
C368 1-130-495-00 FILM 0.1MF 5% 50V
C369 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C370 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C371 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C372 1-126-959-11 ELECT 0.47MF 20% 50V
C373 1-126-960-11 ELECT 1MF 20% 50V
C374 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C375 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C376 1-126-964-11 ELECT 10MF 20% 50V
C377 1-130-495-00 FILM 0.1MF 5% 50V
C378 1-136-244-11 FILM 0.1MF 5% 50V
C379 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C380 1-126-942-61 ELECT 1000MF 20% 25V
C381 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C382 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C383 1-130-495-00 FILM 0.1MF 5% 50V
C384 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C385 1-164-182-11 CERAMIC CHIP 0.0033MF 10% 50V
C386 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
A
