— 18 —
KV-32FV1/34FVL1/36FV1
(4) Service Data (1/4)
No.Register Data Initial Average
Name Description Length Data Data COMMENT
VP CXA2095AS
1 VPOS V-Position 0-63 20 21 Adjust
2 VSIZ V-Size 0-63 20 38 Adjust
3 PVSZ V-Size 0-63 20 31 Adjust
4 VCOM V-Compensation 0-3 1 1 Fix
5 VLIN V-Linearity 0-15 7 12 Adjust
6 VSCO S-Correction 0-15 7 8 Adjust
7HPOS H-Position 0-15 7 14 Adjust
8 HSIZ H-Size 0-63 18 23 Adjust
9PHSZ H-Size 0-63 20 9 Adjust
10PAMP PIN-Compensation 0-63 31 19 Adjust
11UPIN Upper-CornerPin 0-15 7 6 Adjust
12LPIN Lower-CornerPin 0-15 7 8 Adjust
13PPHA Pin-Phase 0-15 7 3 Adjust
14AFC AFC 0-3 2 2 Fix
15VBOW AFC-Bow 0-15 7 8 Adjust
16VANG AFC-Angle 0-15 7 3 Adjust
17REF Reference-Position 0-3 2 2 Fix
18GDRV Green-Drive 0-63 31 31 Adjust
19BDRV Blue-Drive 0-63 31 25 Adjust
20GCUT Green-Cutoff 0-15 7 3 Adjust
21BCUT Blue-Cutoff 0-15 7 10 Adjust
224GDR Green-Drive 0-63 31 29 Adjust
234BDR Blue-Drive 0-63 31 24 Adjust
244GCT Green-Cutoff 0-15 7 8 Adjust
254BCT Blue-Cutoff 0-15 7 11 Adjust
26SCON Sub-Contrast 0-15 7 6 Adjust
27SHUE Sub-Hue 0-15 7 6 Adjust
28SCOL Sub-Color 0-15 7 7 Adjust
29SBRT Sub-Brightness 0-63 31 30 Adjust
30SSHP Sub-Sharpness 0-15 7 7 Fix
31CDM2 Count Down Mode2 0, 1 1 1 Fix
32DPIX Dynamic-Picture 0, 1 1 1 Fix
33Y-DC DC-Transmission 0, 1 1 1 Fix
34ABLM ABL 0, 1 1 1 Fix
35NOTC ChromaTrap 0, 1 0 0 Fix
36CROM ChromaTrap-Adjust 0-15 7 7 Fix
37TOT TOT-Filter 0, 1 1 1 Fix
38PREL Pre/Over-Shoot 0-3 0 0 Fix
39SHPF Sharpness-f0 0-3 2 2 Fix
40RON Red-Off 0, 1 1 1 Fix
41GON Green-Off 0, 1 1 1 Fix
42BON Blue-Off 0, 1 1 1 Fix
43CDMD V-Countdown 0, 1 0 0 Fix
44HBSW HBLKSW 0, 1 0 0 Fix
45LBLK Left Blanking 0-15 7 7 Fix
46RBLK Right Blanking 0-15 7 7 Fix
AP BH3856
47SVOL Sub-Volume 0-15 0 0 Fix
48SBAL Sub-Balance 0-15 7 7 Fix
49SBAS Sub-Bass 0-15 7 7 (Fix by Model)
50STRE Sub-Treble 0-15 7 7 (Fix by Model)
TS TC9447F
51TB0U B0h Upper 8bit 0-255 0 0 Fix
52TB0L B0h Lower 8bit 0-255 0 0 Fix
53TB1U B1h Upper 8bit 0-255 0 0 Fix
54TB1L B1h Lower 8bit 0-255 0 0 Fix
55TB2U B2h Upper 8bit 0-255 57 57 Fix
56TB2L B2h Lower 8bit 0-255 0 0 Fix
57TBFU BFh Upper 8bit 0-255 166 166 Fix
58TBFL BFh Lower 8bit 0-255 0 0 Fix
59TC0U C0h Upper 8bit 0-255 90 90 Fix
60TC0L C0h Lower 8bit 0-255 0 0 Fix
61TC1U C1h/C7h Upper 8bit 0-255 79 49 Fix
62TC1L C1h/C7h Lower 8bit 0-255 0 0 Fix
63MADU ADh Upper 8bit 0-255 64 64 Fix
64MADL ADh Lower 8bit 0-255 0 0 Fix
65MB0U B0h Upper 8bit 0-255 92 92 Fix
66MB0L B0h Lower 8bit 0-255 0 0 Fix
