— 20 —
KV-32FV1/34FVL1/36FV1
No. Register Data Initial Average
Name Description Length Data Data Adj/Fix
PP SAB9076
125 SMT6 SMART6 0, 1 1 1 Fix
126 SKP6 SKIP6 0, 1 0 0 Fix
127 BGHP BGhfp 0-15 7 8 Adjust
128 BGVP BGvfp 0-15 8 8 Adjust
129 MAHP MAhfp 0-15 6 6 Adjust
130 MAVP MAvfp 0-255 24 24 Adjust
131 SAHP SAhfp 0-15 3 3 Fix
132 SAVP SAvfp 0-255 24 24 Fix
133 VPED PedestV 0-15 14 0 Fix
134 UPED PedestU 0-15 14 0 Fix
135 MDEC Main Decoder Setting 0- 32 18 18 Fix
136 SDEC Sub Decoder Setting 0- 32 16 16 Fix
137 DISS Display Setting 0-126 2 2 Fix
138 BSIZ Border Size 0-255 34 34 Fix
139 POFH PIP Offset H 0- 15 11 11 Fix
140 POFV PIP Offset V 0- 15 6 6 Fix
141 DHPS Display H Position Start 0- 15 4 5 Fix
142 P&PV SDhfp , MDhfp under P&P 0-255 62 62 Fix
143 BBR0 BorderColor0 Brightness 0-3 1 1 Fix
144 BCL0 BorderColor0 Color 0-7 7 7 Fix
145 BBR2 BorderColor2 Brightness 0-3 2 2 Fix
146 BCL2 BorderColor2 Color 0-7 6 6 Fix
147 BBR3 BackgroundColor Brightnes
s
0-3 0 0 Fix
148 BCL3 BackgroundColor Color 0-7 7 7 Fix
SP SDA9288
149 PYSD Select Delay 0-15 3 3 Fix
150 PIPH PIP H-Position 0-127 78 78 Fix
151 PIPV PIP V-Position 0-63 18 18 Fix
152 PYDL PIP Y-delay 0-7 0 0 Fix
153 PHDL H-pulse delay 0-15 3 3 Fix
154 PMVD Main V-pulse delay 0-31 16 16 Fix
155 PIVD Inset V-pulse delay 0-31 22 22 Fix
156 PCON Inset Contrast 0-15 7 7 Fix
157 FRMY Frame Y 0-15 7 7 Fix
158 CHRI Input Polarity 0,1 1 1 Fix
159 CHRO Output Polarity 0,1 1 1 Fix
160 IPER Inset Pedestal R-Y 0-15 0 0 Fix
161 IPEB Inset Pedestal B-Y 0-15 0 0 Fix
162 PCPS CLPS BIt Control 0,1 0 0 Fix
163 PCPF CLPFIX BIt Control 0,1 0 0 Fix
164 PSEL SELDOWN Bit Control 0,1 1 1 Fix
165 PPLL PLL Filter Bits 0-3 1 0 Fix
166 PVNR PVNR bit 0, 1 0 1 Fix
MC CXA2019
167 MHUE HUE 0-63 26 26 Fix
168 MCOL COLOR 0-63 35 35 Fix
169 MSCO SUB CONT 0-15 7 7 Adjust
170 MSCL SUB COLOR 0-15 7 7 Adjust
171 MSHU SUB HUE 0-15 7 7 Adjust
172 MTOT TOT ON 0, 1 1 1 Fix
173 MTRP TRAP ON 0, 1 0 0 Fix
174 MTRA CTRAPADJ 0-15 7 7 Fix
175 MCD2 CD MODE2 0, 1 1 1 Fix
176 MFSC FSC OUT 0, 1 1 1 Fix
177 MYDR Y DRIVE 0-31 22 22 Fix
178 MVPE V PED 0-15 7 7 Adjust
179 MUPE U PED 0-15 7 7 Adjust
180 MRVP RV PED 0-15 0 0 Fix
181 MRUP RU PED 0-15 0 0 Fix
182 MDCT DC TRAN 0-7 0 0 Fix
183 MRYD RY DRIVE 0-31 31 31 Fix
184 MPRE PRE OVER 0-3 0 0 Fix
185 MRUD RU DRIVE 0-31 15 15 Fix
186 MRVD RV DRIVE 0-31 15 15 Fix
187 MDLY DELAY 0-3 0 0 Fix
188 MSCR SCP BGR 0-3 1 1 Fix
189 MSCF SCP BGF 0-3 1 1 Fix
Service Data (3/4)
