Sony TRINITRON KV-32FV1 - Page 41

C VOLTAGE
#3
C BOARD TRANSISTOR
VOLTAGE LIST C BOARD IC VOLTAGE LIST
BCE IC1761 IC1762 IC1763
Q1761 4.1 0.1 3.4 pin volt pin volt pin volt
All voltages are in V 1 3.4 1 3.4 1 3.4
2 9.1 2 9.1 2 9.1
3 3.3 3 3.4 3 3.4
4 GND 4 GND 4 GND
5 7.1 5 6.3 5 4.1
6 212.0 6 212.2 6 212.0
7 144.0 7 147.2 7 146.0
8 146.0 8 149.6 8 147.8
9 143.0 9 145.9 9 145.0
All voltages are in V
