Sony TRINITRON KV-32FV1 - Page 50

6 8
6.0 Vp-p (V)
10
4
7
3
2.0 Vp-p (H)
3.2 Vp-p (H)
2
5
1.0 Vp-p (H)
9
P BOARD WAVEFORMS
6.4 Vp-p (H)
4.2 Vp-p (V)
3.9 Vp-p (V)
1
3.2 Vp-p (H)1.9 Vp-p (8MHz)
2.2 Vp-p (H)
