— 63 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
KV-32FV1/34FVL1/36FV1
C1372 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C1373 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C1501¡ 1-117-659-71 FILM 0.1MF 5% 200V
(KV-36FV1 ONLY)
CONNECTOR
CN270 1-573-298-11 CONNECTOR, BOARD TO BOARD 20P
CN271 * 1-691-616-21 CONNECTOR, BOARD TO BOARD 15P
CN351 * 1-564-509-11 PLUG, CONNECTOR 6P
CN382 * 1-564-507-11 PLUG, CONNECTOR 4P
CN501 * 1-580-798-11 CONNECTOR PIN (DY) 6P
CN503 * 1-564-508-11 PLUG, CONNECTOR 5P
CN1001* 1-564-508-11 PLUG, CONNECTOR 5P
CN1002* 1-564-506-11 PLUG, CONNECTOR 3P
CN1101 1-573-298-11 CONNECTOR, BOARD TO BOARD 20P
CN1231* 1-564-512-11 PLUG, CONNECTOR 9P
CN1461* 1-564-507-11 PLUG, CONNECTOR 4P
CN1641* 1-564-515-11 PLUG, CONNECTOR 12P
CN1643* 1-508-784-00 PIN CONNECTOR (5MMPITCH) 1P
CN1941* 1-564-511-11 PLUG, CONNECTOR 8P
CN1942* 1-564-509-11 PLUG, CONNECTOR 6P
CN3001 1-573-297-21 CONNECTOR, BOARD TO BOARD 18P
CN3002 1-573-978-21 CONNECTOR, BOARD TO BOARD 11P
DIODE
D001 8-719-991-33 DIODE 1SS133T-77
D002 8-719-109-89 DIODE RD5.6ESB2
D003 8-719-991-33 DIODE 1SS133T-77
D004 8-719-110-17 DIODE RD10ESB2
D011 8-719-109-72 DIODE RD3.9ESB2
D012 8-719-991-33 DIODE 1SS133T-77
D013 8-719-991-33 DIODE 1SS133T-77
D014 8-719-991-33 DIODE 1SS133T-77
D015 8-719-991-33 DIODE 1SS133T-77
D353 8-719-991-33 DIODE 1SS133T-77
D356 8-719-991-33 DIODE 1SS133T-77
D360 8-719-110-17 DIODE RD10ESB2
D362 8-719-991-33 DIODE 1SS133T-77
D363 8-719-404-49 DIODE MA111
D368 8-719-991-33 DIODE 1SS133T-77
D501 8-719-109-89 DIODE RD5.6ESB2
D502 8-719-945-80 DIODE ERC06-15S
D503 8-719-945-80 DIODE ERC06-15S
D504 8-719-900-26 DIODE ERD29-08J
D505 8-719-908-03 DIODE GP08D
D506 8-719-908-03 DIODE GP08D
D507 8-719-991-33 DIODE 1SS133T-77
D510 8-719-300-33 DIODE RU-3AM
D511 8-719-970-87 DIODE ERA38-06
D512 8-719-970-87 DIODE ERA38-06
D513 8-719-110-41 DIODE RD15ESB2
D515 8-719-302-43 DIODE EL1Z
D516 8-719-991-33 DIODE 1SS133T-77
D518 8-719-991-33 DIODE 1SS133T-77
D519 ¡ 8-719-302-43 DIODE EL1Z
D520 8-719-991-33 DIODE 1SS133T-77
D521 8-719-921-63 DIODE MTZJ-7.5B
D522 8-719-991-33 DIODE 1SS133T-77
D530 8-719-979-85 DIODE EGP20G
D531 8-719-979-85 DIODE EGP20G
D534 8-719-302-43 DIODE EL1Z
D561 8-719-908-03 DIODE GP08D
D1001 8-719-404-49 DIODE MA111
D1002 8-719-404-49 DIODE MA111
D1003 8-719-110-17 DIODE RD10ESB2
D1004 8-719-110-17 DIODE RD10ESB2
D1102 8-719-982-24 DIODE MTZJ-33A
D1103 8-719-109-89 DIODE RD5.6ESB2
D1104 8-719-110-17 DIODE RD10ESB2
D1105 8-719-110-17 DIODE RD10ESB2
D1301 8-719-404-49 DIODE MA111
D1302 8-719-991-33 DIODE SS133T-77
D1304 8-719-991-33 DIODE 1SS133T-77
D1305 8-719-991-33 DIODE 1SS133T-77
D1306 8-719-404-49 DIODE MA111
DELAY LINE
DL351 1-416-231-11 DELAY LINE
FERRITE BEAD
FB501 1-410-397-21 FERRITE 1.1UH
FB502 1-410-397-21 FERRITE 1.1UH
FB503 1-410-397-21 FERRITE 1.1UH
IC
IC001 8-752-886-53 IC CXP85856A-001S
IC002 8-759-353-44 IC ST24C08FM6TR
IC351 8-752-082-73 IC CXA2095S
IC352 8-752-080-75 IC CXA2039M-T6
IC353 8-759-462-91 IC TA1226N
IC501 8-759-700-07 IC NJM2903M
IC561 8-759-192-71 IC STV9379
IC1001 8-752-058-68 IC CXA1315M
CONDUCTOR
JR001 1-216-295-91 SHORT 0
A
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
