Sony TRINITRON KV-32FX20E - C Board; D Board; VM Board; A Board

143 Vp-p (H)
1
139 Vp-p (H)
WAVEFORMS C BOARD
128 Vp-p (H)
3
2
7.3 Vp-p (H)
WAVEFORMS VM BOARD
1
1.1 Vp-p (H) 1.0 Vp-p (H)
5
1.0 Vp-p (H)
1
1.3 Vp-p (H)
2
WAVEFORMS A BOARD
187 mVp-p (H)
7
1.1 Vp-p (H)
1.2 Vp-p (V)
6
3
4
51 Vp-p (H)
51 Vp-p (V)
1
2.7 Vp-p (H)
2
WAVEFORMS D BOARD
12 Vp-p (H)
3
4
