Sony TRINITRON KV-32FX20E - SECTION 7 ELECTRICAL PARTS LIST; A Board Common Parts List; A Board Variant Parts List; C Board Complete Parts List

75
PARTS LISTING TABLE OF CONTENTS
Page
A BOARD COMMON Parts List :
Parts common to all models listed in this manual ............................... 76
A BOARD VARIANT Parts List :
Parts that belong only to the model specified
Model
KV-32FX20A/32FX20B/
KV-32FX20D/32FX20E ................................................................................................... 82
KV-32FX20U ................................................................................................... 82
C BOARD COMPLETE Parts List :
................................................................................................... 82
D1 BOARD COMPLETE Parts List :
................................................................................................... 83
D2 BOARD COMPLETE Parts List :
................................................................................................... 85
D BOARD COMPLETE Parts List :
................................................................................................... 86
VM BOARD COMPLETE Parts List :
................................................................................................... 90
H BOARD COMPLETE Parts List :
................................................................................................... 92
MISCELLANEOUS :
................................................................................................... 93
ACCESSORIES AND PACKAGING MATERIALS :
................................................................................................... 93
Note :
Refer to the designated variant parts list when seeking a part indicated by an asterisk (*)
Parts indicated (
#
) on the Schematic Diagram are not used in this model and
therefore do not appear in the Parts List.
SECTION 7
ELECTRICAL PARTS LIST
