– 52 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG21P40/PG21M70/PG21P70
RM-952
R874 1-215-475-00 METAL 180K 1% 1/4W
R878 1-216-049-11 RES-CHIP 1K 5% 1/10W
R879 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R880 1-216-097-11 RES-CHIP 100K 5% 1/10W
R881 1-216-085-91 RES-CHIP 33K 5% 1/10W
R882 1-216-073-91 RES-CHIP 10K 5% 1/10W
R883 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R884 1-216-089-91 RES-CHIP 47K 5% 1/10W
R885 1-216-073-91 RES-CHIP 10K 5% 1/10W
R886 1-216-295-91 SHORT 0
R887 1-215-477-00 METAL 220K 1% 1/4W
R888 1-215-477-00 METAL 220K 1% 1/4W
R889 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
<SWITCH>
S001 1-692-431-21 SWITCH, TACTILE
S002 1-692-431-21 SWITCH, TACTILE
S003 1-692-431-21 SWITCH, TACTILE
S004 1-692-431-21 SWITCH, TACTILE
S005 1-692-431-21 SWITCH, TACTILE
S006 1-692-431-21 SWITCH, TACTILE
S600 1-571-433-21 SWITCH, PUSH (AC POWER)
S800 1-572-707-11 SWITCH, LEVER
<#########>
SWF100 1-781-042-11 FILTER, SURFACE WAVE
<TRANSFORMER>
T503 1-453-329-21 TRANSFORMER ASSY FLY BACK
(NX-4751//M3A4)
T600 1-431-747-11 TRANSFORMER, LINE FILTER
T601 1-437-333-11 TRANSFORMER, CONVERTER (SRT)
T800 1-435-374-11 TRANSFORMER, FERRITE (HDT)
<THERMISTOR>
THP600 1-803-744-11 THERMISTOR, POSITIVE
<TUNER>
TU100 8-598-591-00 TUNER, VSS BT-AG402
<VARISTOR>
VDR600 1-803-830-11 VARISTOR (ERZV14D621)
<CRYSTAL>
X001 1-577-358-21 VIBRATOR, CERAMIC
X300 1-567-505-11 OSCILLATOR, CRYSTAL
X301 1-567-504-11 OSCILLATOR, CRYSTAL
*************************************************************
* A-1332-200-A CV BOARD MOUNTED
*********************
4-382-854-01 SCREW (M3X8), P, SW (+)
<CAPACITOR>
C701 1-115-350-51 CERAMIC 0.0047UF 2KV
C702 1-102-074-00 CERAMIC 0.001UF 10.00% 50V
C703 1-107-651-11 ELECT 4.7UF 20.00% 250V
C704 1-130-202-00 FILM 0.022UF 5.00% 400V
C706 1-126-947-11 ELECT 47UF 20.00% 16V
C708 1-102-114-00 CERAMIC 470PF 10.00% 50V
C709 1-102-114-00 CERAMIC 470PF 10.00% 50V
C710 1-102-114-00 CERAMIC 470PF 10.00% 50V
C712 1-102-115-00 CERAMIC 560PF 10.00% 50V
C713 1-102-116-00 CERAMIC 680PF 10.00% 50V
C714 1-102-116-00 CERAMIC 680PF 10.00% 50V
C716 1-126-933-11 ELECT 100UF 20.00% 16V
C717 1-102-852-91 CERAMIC 47PF 5.00% 50V
C718 1-126-933-11 ELECT 100UF 20.00% 16V
C719 1-102-116-00 CERAMIC 680PF 10.00% 50V
<CONNECTOR>
CN701 * 1-564-508-11 PLUG, CONNECTOR 5P
CN702 1-695-915-11 TAB (CONTACT)
CN703 * 1-564-509-11 PLUG, CONNECTOR 6P
CN704 1-695-915-11 TAB (CONTACT)
<DIODE>
D701 8-719-911-19 1SS119-25
D702 8-719-911-19 1SS119-25
D703 8-719-911-19 1SS119-25
D707 8-719-911-19 1SS119-25
D708 8-719-911-19 1SS119-25
D709 8-719-911-19 1SS119-25
D713 8-719-911-19 1SS119-25
D714 8-719-911-19 1SS119-25
D715 8-719-911-19 1SS119-25
D716 8-719-911-19 1SS119-25
D717 8-719-070-16 NNCD9.1A-T1
<JACK>
J701 ! 1-540-071-22 SOCKET, CRT
<COIL>
L701 1-414-185-41 INDUCTOR 22UH
L710 1-414-186-31 INDUCTOR 33UH
L711 1-414-185-41 INDUCTOR 22UH
L712 1-414-185-41 INDUCTOR 22UH
<TRANSISTOR>
Q704 8-729-326-11 2SC2611
Q705 8-729-326-11 2SC2611
Q706 8-729-326-11 2SC2611
Q707 8-729-200-17 2SA1091-O
Q708 8-729-200-17 2SA1091-O
CV
A
