– 53 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG21P40/PG21M70/PG21P70
RM-952
Q709 8-729-200-17 2SA1091-O
Q710 8-729-119-78 2SC2785-HFE
Q711 8-729-119-78 2SC2785-HFE
Q712 8-729-119-78 2SC2785-HFE
<RESISTOR>
R703 1-219-752-11 CARBON 100K 5% 1/2W
R706 1-215-417-00 METAL 680 1% 1/4W
R707 1-215-413-00 METAL 470 1% 1/4W
R708 1-216-387-11 METAL OXIDE 0.68 5% 3W
R710 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R711 1-260-330-11 CARBON 1.5K 5% 1/2W
R712 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R713 1-260-330-11 CARBON 1.5K 5% 1/2W
R714 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R715 1-260-330-11 CARBON 1.5K 5% 1/2W
R716 1-249-923-11 CARBON 1K 5% 1/4W
R717 1-249-923-11 CARBON 1K 5% 1/4W
R718 1-249-923-11 CARBON 1K 5% 1/4W
R725 1-249-421-11 CARBON 2.2K 5% 1/4W
R726 1-249-421-11 CARBON 2.2K 5% 1/4W
R727 1-249-421-11 CARBON 2.2K 5% 1/4W
R728 1-249-408-11 CARBON 180 5% 1/4W
R729 1-249-408-11 CARBON 180 5% 1/4W
R730 1-249-408-11 CARBON 180 5% 1/4W
R731 1-249-407-11 CARBON 150 5% 1/4W
R732 1-249-407-11 CARBON 150 5% 1/4W
R733 1-249-407-11 CARBON 150 5% 1/4W
R734 1-219-743-11 CARBON 100 5% 1/2W
R738 1-247-807-31 CARBON 100 5% 1/4W
R739 1-247-807-31 CARBON 100 5% 1/4W
R740 1-247-807-31 CARBON 100 5% 1/4W
R755 1-249-418-11 CARBON 1.2K 5% 1/4W
R756 1-249-418-11 CARBON 1.2K 5% 1/4W
R757 1-249-418-11 CARBON 1.2K 5% 1/4W
<VARIABLE RESISTOR>
RV702 1-241-656-11 RES, ADJ, METAL FILM 110M
**************************************************************
ACCESSORIES AND PACKING MATERIALS
***************************************
3-701-910-00 SCREW, SPECIAL (DIA. 3.8X20)
* 4-083-905-11 INDIVIDUAL CARTON
(KV-PG21M70/PG21P70)
* 4-083-905-02 INDIVIDUAL CARTON
(KV-PG21P40(SINGAPORE)/
PG21P40(MALAYSIA)
* 4-085-465-01 CUSHION LOWER (KV-PG21M70/PG21P70)
* 4-085-466-01 CUSHION UPPER (KV-PG21M70/PG21P70)
* 4-395-957-01 BAG, PROTECTION
4-084-172-11 MANUAL INSTRUCTION
(KV-PG21P40(MALAYSIA)/
PG21P40(SINGAPORE)
4-084-862-11 MANUAL INSTRUCTION (KV-PG21M70)
4-084-172-31 MANUAL INSTRUCTION (KV-PG21P70)
4-392-003-11 BAND, HOLD
4-392-004-11 CLIP
*************************************************************
REMOTE COMMANDER
**********************
1-418-163-51 REMOTE COMMANDER (RM-952)
9-939-697-01 COVER BATTERY REMOTE COMMANDER
CV
