Sony TRINITRON PVM-14L1 - Disassembly (14 Inch); Cabinet and Rear Panel (14 Inch)

1-2
PVM-14L1/14L1MDE/20L1
SSM-14L1/20L1
1-3. Disassembly (14 inch)
1-3-1. Cabinet and Rear Panel (14 inch)
A
B
1 Six nylon rivets
2
Two case claw screws
(M 4 x 8)
3
Two case claw screws
(M 4 x 8)
5 Four screws
(+BVTP 4 x 16)
6 Remove the rear panel
in the direction of the arrow B.
4 Remove the cabinet
in the direction of the arrow A.
