Sony Trinitron PVM-14N1E Service Manual

Transport & Storage Condition
Storage Temperature—10 to +40°C (14 tol104°F)
Humidity 0 to 90 %
Pressure 700 to 1060 hpa (PVM-14N1MDE)
Dimensions (w/h/d) PVM- 14N1A/14N1E/14NIMDE/
14N1U/14N2A/14N2E/14N2U,
SSM-14N1E/14N1U
3346 x 340 x 414 mm
(13%x 1314 x 16% inches)
PVM-20N1A/20N1E/20N1U/20N2A/
20N2E/20N2U,
SSM-20N1E/20N1U:
449 x 441x 502 mm
(1734 x17 x 197% inches)
Mass PVM- 14N1A/14N1E/14N1IMDE/
14N1U/14N2A/14N2E/14N2U,
SSM-14N1E/14N1U:
Approx. 15 kg (33 Ib 1 0z)
PVM- 20N1A/20N1E/20N1U/20N2A/
20N2E/20N2U,
SSM-20N1E/20N1U:
Approx. 28 kg (61 Ib 12 oz)
Accessory supplied AC power cord (1)
Operating Instructions (1)
PVM-14NIMDE
:Splash-proof covers (2)
(PVM-14N1MDE only)
Electromagnetic C
Compatibility
Pin assignment
Y/C IN connector (4-pin mini-DIN)
Vp-p, sync negative “|
75 ohms
286m Vp-p (NTSC),
300m Vp-p (PAL),
burst
Delay time between Y
and C: within 0 + 100
nsec., 75 ohms
GND for Y-input | GND
GND for
CHROMA-input
CHROMA
subcarrier-input
Design and specifications are subject to change without
notice.
This device compiles with the requirements of Directive 89/336/EEC concerning
electromagnetic compatibility.
This device meets EN50081-1/92 and EN50082-1/92.
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND THE
ANODE CAP TO THE METAL CHASSIS, CRT SHIELD, OR CARBON
PAINTED ON THE CRT, AFTER REMOVING THE ANODE.
WARNING!!!
AN ISOLATION TRANSFORMER SHOULD BE USED DURING ANY
SERVICE TO AVOID POSSIBLE SHOCK HAZARD, BECAUSE OF
LIVE CHASSIS.
THE CHASSIS OF THIS RECEIVER IS DIRECTLY CONNECTED TO
THE AC POWER LINE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARKA ON THE
SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY. CIRCUIT ADJUSTMENTS THAT ARE
CRITICAL TO SAFE OPERATION ARE IDENTIFIED IN THIS MANUAL.
FOLLOW THESE PROCEDURES WHENEVER CRITICAL
COMPONENTS ARE REPLACED OR IMPROPER OPERATION iS
SUSPECTED. ,
ATTENTION
APRES AVOIR DECONNECTE LE CAP DE L'ANODE,
COURTCIRCUITER L'ANODE DU TUBE CATHODIQUE ET CELUI
DE L'ANODE DU CAP AU CHASSIS METALLIQUE DE L' APPAREIL,
OU AU COUCHE DE CARBONE PEINTE SUR LE TUBE CAT HODIQUE
OU AU BLINDAGE DU TUBE CATHODIQUE.
ATTENTION!!
AFIN D'EVITER TOUT RISQUE D'ELECTROCUTION PROVENANT
D'UN CHASSIS SOUS TENSION, UN TRANSFOR MATEUR
D'SOLEMENT DOIT ETRE UTILISE LORS DE TOUT DiPANNAGE.
LE CHASSIS DE CE RECEPTEUR EST DIRECTEMENT tAACCORDE
A L'ALIMENTATION SECTEUR.
ATTENTION AUX COMPOSANTS RELATIFS A Las
SECURITE!!
LES COMPOSANTS IDENTIFIES PAR UNE TRAME E] PAR UNE
MARQUE A SUR LES VUES EXPLOSEES ET LES IISTES DE
PIECES SONT D'UNE IMPORTANCE CRITIQUE PUR LASSECURITE
DU FONCTIONNEMENT. NE LES REMPLACER QUE PAR DES
COMPOSANTS SONY DONT LE NUMERO DE PIECE EST INDIQUE
DANS LE PRESENT MANUEL OU DANS DES SUPIL EMENTS
PUBLIES PAR SONY.
