Sony UP-X898MD Service Manual

5-2
UP-D898MD/X898MD
5-2. Exploded Views
Top Cover and Door Panel Block (UP-D898MD)
To SE-1142
board
To SU-167
board
To Stepping
motor
A
A
B
B
PSW
3 ) 8
P3 ) 4
P3 ) 4
PSW
3 ) 8
PS4 ) 8
B3 ) 6
B3 ) 6
B3 ) 6
D
D
G
H
H
J
J
K
G
C
C
K
8
1
4
5
13
12
11
10
6
7
9
3
2
BVTT
2.6 ) 5
BVTT
2.6 ) 4
BVTT
2.6 ) 4
LW6
W4
N6

Sony UP-X898MD Specifications

General

Color	No
Resolution	162.5 lpi
Control type	Buttons, Rotary
Certification	(US/CA) ANSI/AAMI ES60601-1, UL 60601-1, UL 60950-1, CAN/CSA-C22.2 No.60601-1, CAN/CSA C22.2 No.601.1, CAN/CSA C22.2 No.60950-1 (EU) EN 60601-1, EN 60950-1 (CB) IEC 60601-1 (2nd/3rd Ed.), IEC 60950-1 (US/CA) FCC Part 15 Subpart-B Digital Device Class A, ICES-003 Class A Digital Apparatus (EU) EN 60601-1-2 (Class B), EN 55022 (Class B)+EN 55024, EN 61000-3-2+ EN 61000-3-3 (AU) AS/NZS CISPR22 (EN55022) Class B (JP) VCCI Class A, JIS C 61000-3-2 (KR) KN22, KN24 Class B (EU) MDD, EMC, LVD
Product color	White
Printing colors	Black
Built-in display	Yes
Grayscale levels	256
Print technology	Direct thermal printing
Printing time (max)	1.9 s
Printing time (min)	3.3 s
Maximum printing width	110 mm
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	1
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Input current (max)	1.3 A
Input current (min)	0.6 A
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	USB

Weight and Dimensions

Depth	240 mm
Width	154 mm
Height	88 mm
Weight	2500 g
