Specifications
HDMI terminal (HDMI, fermale)
Acceptable Input Signals
Computer signal
1 T.M.D.S.
Data2+
11 T.M.D.S.
Clock Shield
2 T.M.D.S.
Data2 Shield
12 T.M.D.S.
Clock–
3 T.M.D.S.
Data2–
13 NC
4 T.M.D.S.
Data1+
14 RECERVED
(N.C.)
5 T.M.D.S.
Data1 Shield
15 SCL
6 T.M.D.S.
Data1–
16 SDA
7 T.M.D.S.
Data0+
17 GND
8 T.M.D.S.
Data0 Shield
18 +5V Power
9 T.M.D.S.
Data0–
19 Hot Plug
Detect
10 T.M.D.S.
Clock+
Resolution
fH [kHz]/
fV [Hz]
Input terminal
RGB
*1
DVI-D
*2
/
HDMI
*3 *6
640 × 350 31.5/70 z –
37.9/85
z –
640 × 400 31.5/70
z –
37.9/85
z –
640 × 480 31.5/60
zz
35.0/67 z –
37.9/73
z –
37.5/75
z –
43.3/85
z –
800 × 600 35.2/56
z –
37.9/60
zz
48.1/72 z –
46.9/75
z –
53.7/85
z –
832 × 624 49.7/75
z –
1024 × 768 48.4/60
zz
56.5/70 z –
60.0/75
z –
68.7/85
z –
1152 × 864 64.0/70
z –
67.5/75
z –
77.5/85
z –
1152 × 900 61.8/66
z –
1280 × 960 60.0/60
zz
75.0/75 z –
1280 × 1024 64.0/60
zz
80.0/75 z –
91.1/85
z –
1400 × 1050 65.3/60
zz
1600 × 1200 75.0/60 zz
1280 × 768 47.8/60 zz
1280 × 720 45.0/60 zz
*7
