Location and Function of Controls
Input (page 8)
a INPUT A
Video: RGB/YPBPR input terminal
(RGB HD VD/YP
BPR)
Audio: Audio input terminal (AUDIO)
b INPUT B
Video: RGB input terminal (RGB)
Audio: Audio input terminal (AUDIO)
c INPUT C
Video: DVI-D input terminal (DVI-D)
Audio: Audio input terminal (AUDIO)
d INPUT D (VPL-FH36/FH35/FH31/
FH30 only)
Video: HDMI input terminal (HDMI)
Audio: HDMI input terminal (HDMI)
e S VIDEO (S VIDEO IN)
Video: S video input terminal
Audio: Audio input terminal (AUDIO L
[MONO]/R)
f VIDEO (VIDEO IN)
Video: Video input terminal
Audio: Audio input terminal (AUDIO L
[MONO]/R)
• The audio input terminals of the projector are
for output to external equipment.
Connect
external audio equipment to output an
audio
(page 11).
• The audio inputs of INPUT B and INPUT C
are shared. The audio inputs of S VIDEO
and VIDEO also are shared.
Output (page 11)
g OUTPUT
Video: Monitor output terminal
(MONITOR)
Audio: Audio output terminal (AUDIO)
This terminal outputs the projected image or
audio. The image is output as a computer signal
input from the RGB input terminal (INPUT A,
INPUT B) or a video signal input from the
YP
BPR input terminal (INPUT A).
Others
h RS-232C terminal
RS-232C compatible control terminal
i LAN terminal (page 33)
j CONTROL S input terminal (DC
power supply) (CONTROL S IN
PLUG IN POWER)
Connects to the CONTROL S output
terminal on the supplied Remote
Commander with a connecting cable
(stereo mini plug (not supplied)) when
using it as a wired Remote Commander.
You do not need to install batteries in the
Remote Commander, as the power is
supplied from this terminal.
k AC IN (∼) socket
Connects the supplied AC power cord.
