Sony VPL-FX35 - Page 51

51
Specifications
Others
Computer and
video signal input/
output
INPUT A RGB/YP
BPR input terminal: 5BNC female, G with
sync/Y: 1 Vp-p ± 2 dB, sync negative, 75 ohms
terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB, 75 ohms
terminated, Sync signal: TTL level high impedance,
positive/negative
Audio input terminal: Stereo mini jack, rated input 500
mVrms, input impedance more than 47 kilohms
INPUT B RGB input terminal: Mini D-sub 15-pin female, RGB:
0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync signal: TTL
level high impedance, positive/negative
Audio input terminal: Stereo mini jack, rated input 500
mVrms, input impedance more than 47 kilohms
INPUT C DVI-D input terminal: DVI-D 24-pin (Single link), DVI
1.0 compliant, HDCP support
Audio Input terminal: Shared with INPUT B
INPUT D
*2
HDMI input terminal: Digital RGB/YPBPR, Digital
audio: PCM (32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96
kHz)
S VIDEO IN S video input terminal: Mini DIN 4-pin, Y: 1 Vp-p ± 2
dB, sync negative, 75 ohmes terminated, C: (burst signal)
0.286 (NTSC)/0.3 (PAL/SECAM) Vp-p ± 2 dB, 75 ohms
terminated
Audio input terminal: Phono jack × 2, rated input 500
mVrms, Input impedance more than 47 kilohms
VIDEO IN Video input terminal: Phono jack, 1 Vp-p ± 2 dB, sync
negative, 75 ohmes terminated
Audio input terminal: Shared with S VIDEO IN
OUTPUT MONITOR output terminal: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative, 75
ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB, 75 ohms
terminated, Sync signal: HD, VD 4 V (open), 1 Vp-p (75
ohms), positive/negative
Audio output terminal: Stereo mini jack, stereo, 1
Vrms (maximum volume, when inputting 500 mVrms),
output impedance 5 kilohms
Control signal
input/output
RS-232C terminal: D-Sub 9 pin female
LAN terminal: RJ45, 10BASE-T/100BASE-TX
CONTROL S input terminal (DC power supply):
Stereo mini jack, 5 Vp-p, Plug in power DC 5 V
Operating
temperature/
Operating
humidity
0 °C to 40 °C (32 °F to 104 °F)/35% to 85% (no
condensation)
Storage
temperature/
Storage humidity
–20 °C to +60 °C (–4 °F to +140 °F)/ 10% to 90%
Item Description
Model name VPL-FH36/FH35/FH31/FH30/VPL-FX37/FX35/FX30
