– 6 –
2-3. MECHANISM DECK
2-4. BELT, MOTOR (CAPSTAN/REEL) (M901)
Mechanism deck
Center cabinet
2
1
Claws
1
belt
3
Motor (Capstan/reel) (M901)
wheel assy (SP), capstan
belt
• How to apply the belt
M901
2
Screws (M1.4)
