Sony Walkman WM-FX571 Service Manual

– 32 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
AUDIO
A-3061-472-A AUDIO BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C102 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C103 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C104 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C105 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C106 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C108 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C109 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C111 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C112 1-115-156-11 CERAMIC CHIP 1uF 10V
C113 1-115-156-11 CERAMIC CHIP 1uF 10V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C117 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C201 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C202 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C203 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C204 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C205 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C206 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C208 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C209 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C212 1-115-156-11 CERAMIC CHIP 1uF 10V
C213 1-115-156-11 CERAMIC CHIP 1uF 10V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C216 1-115-156-11 CERAMIC CHIP 1uF 10V
C217 1-115-156-11 CERAMIC CHIP 1uF 10V
C219 1-115-156-11 CERAMIC CHIP 1uF 10V
C301 1-135-316-11 TANTAL. CHIP 22uF 20% 2.5V
C302 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C303 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C304 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C305 1-135-316-11 TANTAL. CHIP 22uF 20% 2.5V
C306 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C307 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C308 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C309 1-115-156-11 CERAMIC CHIP 1uF 10V
C310 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C311 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C312 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C313 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C314 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C315 1-115-156-11 CERAMIC CHIP 1uF 10V
C316 1-115-156-11 CERAMIC CHIP 1uF 10V
C317 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C318 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C319 1-107-688-11 TANTAL. CHIP 1.5uF 20% 10V
C320 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C321 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C601 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C602 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C603 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C607 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C608 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C701 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C702 1-115-156-11 CERAMIC CHIP 1uF 10V
C703 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN301 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN701 1-779-079-11 CONNECTOR, BOARD TO BOARD
< DIODE >
D701 8-719-404-50 DIODE MA111-TX
D702 8-719-049-09 DIODE 1SS367-T3SONY
D703 8-719-423-35 DIODE MA8120-H
D704 8-719-423-35 DIODE MA8120-H
D705 8-719-423-35 DIODE MA8120-H
< FERRITE BEAD >
FB703 1-414-760-21 INDUCTOR, FERRITE BEAD
FB704 1-414-760-21 INDUCTOR, FERRITE BEAD
FB705 1-414-235-22 INDUCTOR, FERRITE BEAD
