Sony Walkman WM-FX571 Service Manual

– 4 –
1 screw (M1.7 × 6)
5 TUNER board
4
3
screw
(M1.4
× 4.5)
7 guide (TU)
6
2 screw (M1.7 × 3)
1 screw (M1.7 × 6
)
6 case assy
4 claws
3 screws
(M1.4
× 2.2)
1 screw
(M1.4
× 2.2)
2 screw
(M1.4
× 3.0)
5
CASE ASSY
TUNER BOARD
AUDIO BOARD
CASSETTE LID ASSY
TAPE MECHANISM DECK
SET
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. CASE ASSY
3-2. TUNER BOARD
Note : Disassemble the unit in the order as shown below.

Sony Walkman WM-FX571 Specifications

General

Brand	Sony
Model	Walkman WM-FX571
Category	Cassette Player
Language	English
