– 5 –
2
screw (M1.4
×
2)
5
cassette lid assy
3
screw (M1.4
×
1.6
)
1
OPEN button
4
7
AUDIO board
1
Unsolder the 3 places.
2
battery terminal (–)
4
battery terminal (+)
3
Unsolder the 5 places.
5
Flexible board
6
3-3. AUDIO BOARD
3-4. CASSETTE LID ASSY
