Sony WM-EX2000 User Manual

NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• Abbreviation
CH: Chinese model
KR: Korean model
JE: Tourist model
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 26 —
SECTION 8
ELECTRICAL PARTS LIST
* A-3021-341-A MAIN BOARD, COMPLETE
*********************
3-032-323-01 PAPER (A), SHIELD
< CAPACITOR >
C101 1-107-520-11 TANTAL. CHIP 33uF 20.00% 2.5V
C103 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C104 1-127-988-11 CERAMIC CHIP 15000PF 10% 16V
C105 1-127-988-11 CERAMIC CHIP 15000PF 10% 16V
C106 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-115-156-11 CERAMIC CHIP 1uF 10V
C109 1-115-156-11 CERAMIC CHIP 1uF 10V
C110 1-115-156-11 CERAMIC CHIP 1uF 10V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
C112 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C113 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C201 1-107-520-11 TANTAL. CHIP 33uF 20.00% 2.5V
C203 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C204 1-127-988-11 CERAMIC CHIP 15000PF 10% 16V
C205 1-127-988-11 CERAMIC CHIP 15000PF 10% 16V
C206 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-115-156-11 CERAMIC CHIP 1uF 10V
C209 1-115-156-11 CERAMIC CHIP 1uF 10V
C210 1-115-156-11 CERAMIC CHIP 1uF 10V
C211 1-115-156-11 CERAMIC CHIP 1uF 10V
C212 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C213 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C301 1-113-600-11 TANTAL. CHIP 2.2uF 20.00% 6.3V
C302 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C303 1-115-156-11 CERAMIC CHIP 1uF 10V
C304 1-127-895-11 TANTAL. CHIP 22uF 20% 4V
C306 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C307 1-113-600-11 TANTAL. CHIP 2.2uF 20.00% 6.3V
C308 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C310 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C311 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C312 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C313 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 16V
C314 1-117-920-11 TANTAL. CHIP 10uF 20.00% 6.3V
C315 1-117-920-11 TANTAL. CHIP 10uF 20.00% 6.3V
C316 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C317 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V
C318 1-164-940-11 CERAMIC CHIP 0.0033uF 10.00% 16V
C319 1-164-874-11 CERAMIC CHIP 100PF 5.00% 16V
C320 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C321 1-115-156-11 CERAMIC CHIP 1uF 10V
C322 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C323 1-125-926-11 TANTAL. CHIP 4.7uF 20% 6.3V
C324 1-125-976-11 TANTAL. CHIP 150PF 20% 2.5V
C325 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C326 1-127-895-11 TANTAL. CHIP 22uF 20% 4V
C327 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 16V
C328 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C329 1-115-156-11 CERAMIC CHIP 1uF 10V
C601 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C602 1-115-156-11 CERAMIC CHIP 1uF 10V
C603 1-115-156-11 CERAMIC CHIP 1uF 10V
C604 1-115-156-11 CERAMIC CHIP 1uF 10V
C605 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C606 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C607 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C608 1-119-663-11 TANTAL. CHIP 47uF 20.00% 2.5V
C609 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C610 1-127-671-11 CERAMIC CHIP 10000PF 5% 50V
C611 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 16V
C612 1-113-600-11 TANTAL. CHIP 2.2uF 20.00% 6.3V
C701 1-135-259-11 TANTAL. CHIP 10uF 20.00% 6.3V
C702 1-115-156-11 CERAMIC CHIP 1uF 10V
C703 1-115-156-11 CERAMIC CHIP 1uF 10V
C704 1-115-156-11 CERAMIC CHIP 1uF 10V
C705 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
C706 1-115-156-11 CERAMIC CHIP 1uF 10V
C707 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C708 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C709 1-115-156-11 CERAMIC CHIP 1uF 10V
C710 1-115-156-11 CERAMIC CHIP 1uF 10V
CB301 1-127-575-21 CERAMIC CHIP 470PF 50V
< DIODE >
D701 8-719-073-01 DIODE MA111-(K8).S0
D702 8-719-072-70 DIODE MA2ZD14001S0
< FUSE >
F701 1-576-439-21 FUSE (SMD) 0.25A 125V
< FERRITE BEAD >
FB701 1-414-760-21 INDUCTOR 0uH
MAIN
