Sony WM-EX2000 - Belt and Motor Replacement; Holder (FA) Assembly Disassembly

— 7 —
2 Two screws (M1.4)
4 Motor (M601)
3 Retainer (F1), moto
r
1 Belt (F0)
Belt (F0)
3-5. BELT (F0), MOTOR (M601)
3-6. HOLDER (FA) ASSY
8 Screw (M1.4)
qa Remove soldering
from Head flexible board.
0 Bracket (CASSETTE) assy
9 Shaft
6 Shaft
5 Two screws (M1.4)
7 Lever (B) assy, lock
qd Remove the holder (FA
)
assy in the direction
of the arrow.
2 Screw
(M1.4)
qs Head flexible
board
3 Hook, spring
1 Spring, tension
4 Spring, tension
Ver 1.2 2003. 11
