Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 28 —
WM-EX2000
R611 1-218-983-11 RES-CHIP 330K 5% 1/16W
R612 1-218-989-11 RES-CHIP 1M 5% 1/16W
R613 1-218-989-11 RES-CHIP 1M 5% 1/16W
R614 1-218-977-11 RES-CHIP 100K 5% 1/16W
R701 1-218-935-11 RES-CHIP 33 5% 1/16W
R702 1-218-977-11 RES-CHIP 100K 5% 1/16W
R703 1-218-971-11 RES-CHIP 33K 5% 1/16W
R704 1-218-971-11 RES-CHIP 33K 5% 1/16W
R705 1-218-973-11 RES-CHIP 47K 5% 1/16W
R706 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R707 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R708 1-218-985-11 RES-CHIP 470K 5% 1/16W
R709 1-218-977-11 RES-CHIP 100K 5% 1/16W
R710 1-218-985-11 RES-CHIP 470K 5% 1/16W
R711 1-218-973-11 RES-CHIP 47K 5% 1/16W
R712 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R713 1-218-987-11 RES-CHIP 680K 5% 1/16W
R714 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R715 1-218-987-11 RES-CHIP 680K 5% 1/16W
R716 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R717 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R718 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R719 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R720 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R721 1-208-699-11 RES-CHIP 4.7K 0.5% 1/16W
R722 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R723 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R724 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R725 1-218-953-11 RES-CHIP 1K 5% 1/16W
R726 1-218-985-11 RES-CHIP 470K 5% 1/16W
R727 1-218-985-11 RES-CHIP 470K 5% 1/16W
R728 1-218-985-11 RES-CHIP 470K 5% 1/16W
R729 1-218-985-11 RES-CHIP 470K 5% 1/16W
R730 1-218-981-11 RES-CHIP 220K 5% 1/16W
< VARIABLE RESISTOR >
RV601 1-223-325-21 RES, ADJ, METAL GLAZE 100K
< SWITCH >
S301 1-692-605-11 SWITCH, SLIDE (w VOL)
S701 1-762-516-11 SWITCH, PUSH (1 KEY)(A/B)
S702 1-771-475-11 SWITCH, SLIDE (REW/CONT/FF)
S703 1-771-816-11 SWITCH, LEVER (SLIDE) (JOG Y/x)
< VIBRATOR >
X701 1-579-258-11 VIBRATOR, CRYSTAL 32.768kHz
************************************************************
MISCELLANEOUS
**************
HP701 1-500-676-11 HEAD, MAGNETIC (PLAYBACK)
M601 1-763-559-11 MOTOR, DC (WITH PULLEY)
PM701 1-454-674-31 SOLENOID, PLUNGER
S704 1-762-553-11 SWITCH, LEAF
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-418-262-22 ADAPTOR, AC (AC-E455G)(AEP)
0 1-467-009-21 ADAPTOR, AC (AC-E455D)(US)
0 1-467-550-11 ADAPTOR, AC (AC-E455A)(JE)
0 1-473-116-31 ADAPTOR, AC (AC-E455F)(AEP)
0 1-475-622-11 ADAPTOR, AC (AC-E455)(CH)
0 1-569-007-11 ADAPTOR, CONVERSION 2P(JE)
1-756-120-11 BATTERY, NICKEL HYDROGEN(JE)
1-756-120-21 BATTERY, NICKEL HYDROGEN(US,AEP,CH,KR)
3-008-521-01 CASE, BATTERY CHARGE
3-221-645-01 MANUAL, INSTRUCTION(JAPANESE)(JE)
3-221-645-11 MANUAL, INSTRUCTION
(ENGLISH,CHINESE,KOREAN)(US,CH,JE,KR)
3-221-645-21 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,GERMAN)(AEP)
3-221-645-31 MANUAL, INSTRUCTION
(SPANISH,PORTUGUESE,ITALIAN)(AEP)
3-221-645-41 MANUAL, INSTRUCTION
(DUTCH,SWEDISH,FINNISH)(AEP)
3-222-163-01 POUCH, CARRYING
8-953-811-90 EAR,RECEIVER MDR-E803SP//K SET
A-3052-255-A STAND ASSY (BCA-WM1), CHARGE
A-3052-256-A REMOTE CONTROL ASSY(RM-WME23L)
MAIN
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.1 2001. 01
