– 20 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
JR302 1-216-296-00 SHORT (CHIP) 0
JR303 1-216-296-00 SHORT (CHIP) 0
JR304 1-216-296-00 SHORT (CHIP) 0
JR305 1-216-296-00 SHORT (CHIP) 0
JR306 1-216-296-00 SHORT (CHIP) 0
JR307 1-216-296-00 SHORT (CHIP) 0
JR308 1-216-296-00 SHORT (CHIP) 0
JR309 1-216-296-00 SHORT (CHIP) 0
JR310 1-216-296-00 SHORT (CHIP) 0
JR311 1-216-296-00 SHORT (CHIP) 0
JR313 1-216-296-00 SHORT (CHIP) 0
JR314 1-216-296-00 SHORT (CHIP) 0
JR315 1-216-296-00 SHORT (CHIP) 0
JR316 1-216-296-00 SHORT (CHIP) 0
JR317 1-216-296-00 SHORT (CHIP) 0
JR318 1-216-296-00 SHORT (CHIP) 0
JR319 1-216-296-00 SHORT (CHIP) 0
JR320 1-216-296-00 SHORT (CHIP) 0
JR321 1-216-296-00 SHORT (CHIP) 0
JR322 1-216-296-00 SHORT (CHIP) 0
JR323 1-216-296-00 SHORT (CHIP) 0
JR324 1-216-296-00 SHORT (CHIP) 0
JR325 1-216-296-00 SHORT (CHIP) 0
< RESISTOR >
R101 1-216-089-00 RES,CHIP 47K 5% 1/10W
R102 1-216-089-00 RES,CHIP 47K 5% 1/10W
R103 1-216-079-00 METAL CHIP 18K 5% 1/10W
R104 1-216-075-00 METAL CHIP 12K 5% 1/10W
R105 1-216-117-00 METAL CHIP 680K 5% 1/10W
R106 1-216-046-00 METAL CHIP 750 5% 1/10W
R107 1-216-311-00 METAL CHIP 6.8 5% 1/10W
(EXCEPT FRENCH)
R107 1-216-013-00 METAL CHIP 33 5% 1/10W
(FRENCH)
R109 1-216-095-00 METAL CHIP 82K 5% 1/10W
R110 1-216-049-11 RES,CHIP 1K 5% 1/10W
R111 1-216-174-00 RES,CHIP 100 5% 1/8W
R150 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R201 1-216-089-00 RES,CHIP 47K 5% 1/10W
R202 1-216-089-00 RES,CHIP 47K 5% 1/10W
R203 1-216-079-00 METAL CHIP 18K 5% 1/10W
R204 1-216-075-00 METAL CHIP 12K 5% 1/10W
R205 1-216-117-00 METAL CHIP 680K 5% 1/10W
R206 1-216-046-00 METAL CHIP 750 5% 1/10W
R207 1-216-311-00 METAL CHIP 6.8 5% 1/10W
(EXCEPT FRENCH)
R207 1-216-013-00 METAL CHIP 33 5% 1/10W
(FRENCH)
R209 1-216-095-00 METAL CHIP 82K 5% 1/10W
R210 1-216-049-11 RES,CHIP 1K 5% 1/10W
R211 1-216-025-00 RES,CHIP 100 5% 1/10W
R301 1-216-049-11 RES,CHIP 1K 5% 1/10W
R305 1-216-081-00 METAL CHIP 22K 5% 1/10W
R306 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R309 1-216-113-00 METAL CHIP 470K 5% 1/10W
R324 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R331 1-216-001-00 METAL CHIP 10 5% 1/10W
R332 1-216-081-00 METAL CHIP 22K 5% 1/10W
R333 1-216-688-11 METAL CHIP 36K 0.5% 1/10W
R601 1-216-121-00 RES,CHIP 1M 5% 1/10W
R602 1-216-121-00 RES,CHIP 1M 5% 1/10W
R603 1-216-121-00 RES,CHIP 1M 5% 1/10W
R604 1-216-073-00 METAL CHIP 10K 5% 1/10W
R605 1-216-049-11 RES,CHIP 1K 5% 1/10W
R606 1-216-097-00 RES,CHIP 100K 5% 1/10W
R607 1-216-073-00 METAL CHIP 10K 5% 1/10W
R608 1-216-049-11 RES,CHIP 1K 5% 1/10W
< VARIABLE RESISTOR >
RV301 1-225-544-11 RES, VAR, CARBON 10K/10K (∑ VOLUME)
RV601 1-238-663-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S301 1-762-302-11 SWITCH, PUSH (1 KEY) (FWD/REV)
S302 1-762-917-11 SWITCH, DETECTION (SMALL TYPE) (POWER)
S303 1-692-298-11 SWITCH, SLIDE (TAPE SELECTOR)
(NORM, CrO2/METAL)
S305 1-692-298-11 SWITCH, SLIDE (AVLS) (NORM, LIMIT)
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE (3.3k)
************************************************************
MISCELLANEOUS
***************
1 1-475-441-11 MEGA BASS UNIT (DOLBY)
HP901 1-668-622-11 MAGNETIC HEAD (PLAYBACK)
M901 1-763-073-11 MOTOR (CAPSTAN/REEL)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-020-998-01 CLIP, BELT
3-862-076-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
(East European)
3-862-076-21 MANUAL, INSTRUCTION (ENGLISH, GERMAN,
SPANISH, DUTCH, SWEDISH, ITALIAN,
PORTUGUESE, DANISH) (AEP)
3-862-076-31 MANUAL, INSTRUCTION (FRENCH)
(AEP, French)
3-862-076-41 MANUAL, INSTRUCTION
(GERMAN, POLISH, RUSSIAN, HUNGARIAN,
CZECK, GREEK, TURKISH) (East European)
3-862-076-51 MANUAL, INSTRUCTION
(ENGLISH, CHINESE, KOREAN) (E)
3-862-076-61 MANUAL, INSTRUCTION
(SPANISH, PORTUGUESE) (9E)
8-953-224-90 HEADPHONE MDR-E802LP SET
MAIN
WM-EX372
Sony Corporation
Personal A&V Products Company
9-923-319-11
98B0568-1
Printed in Japan © 1998. 2
Published by Quality Engineering Dept.
(Shibaura)
Ver 1.2 1999. 03
