– 19 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
9E: No indication of country of origin.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
MAIN
When indicating parts by reference
number, please include the board.
A-3021-042-A MAIN BOARD, COMPLETE (EXCEPT French)
A-3021-043-A MAIN BOARD, COMPLETE (French)
*********************
3-019-862-01 TERMINAL (+), BATTERY
3-022-698-01 TERMINAL (–), BATTERY
< CAPACITOR >
C101 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C102 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C104 1-126-157-11 ELECT 10uF 20% 16V
C106 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C131 1-164-346-11 CERAMIC CHIP 1uF 16V
C132 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C133 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C134 1-164-346-11 CERAMIC CHIP 1uF 16V
C201 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C202 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C204 1-126-157-11 ELECT 10uF 20% 16V
C206 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C207 1-164-346-11 CERAMIC CHIP 1uF 16V
C208 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C231 1-164-346-11 CERAMIC CHIP 1uF 16V
C232 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C233 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C234 1-164-346-11 CERAMIC CHIP 1uF 16V
C301 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C303 1-126-153-11 ELECT 22uF 20% 6.3V
C304 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C305 1-126-176-11 ELECT 220uF 20% 10V
C306 1-164-346-11 CERAMIC CHIP 1uF 16V
C307 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C308 1-126-162-11 ELECT 3.3uF 20% 50V
C309 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C310 1-164-346-11 CERAMIC CHIP 1uF 16V
C311 1-164-346-11 CERAMIC CHIP 1uF 16V
C312 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C314 1-164-346-11 CERAMIC CHIP 1uF 16V
C315 1-126-153-11 ELECT 22uF 20% 6.3V
C317 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C318 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C319 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C323 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C331 1-164-346-11 CERAMIC CHIP 1uF 16V
C332 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C333 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C334 1-126-157-11 ELECT 10uF 20% 16V
C601 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C602 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C603 1-126-176-11 ELECT 220uF 20% 10V
C605 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C606 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C607 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C608 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C609 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C610 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
< CONNECTOR >
CN301 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P
* CN302 1-784-527-11 CONNECTOR, FPC (ZIF) 9P
< DIODE >
D150 8-719-067-62 LED LNJ210C6AOSO (BATT)
< IC >
IC301 8-759-332-69 IC LA4585M-TLM
IC331 8-759-488-80 IC NJM2185AV-TE2
IC601 8-759-447-73 IC LB1979V-TLM
< JACK >
J301 1-750-061-11 JACK,DC (POLARITY UNIFIED TYPE) (DC IN 3V)
J302 1-565-287-11 JACK (2)
< JUMPER RESISTOR >
JR201 1-216-295-00 SHORT (CHIP) 0
JR202 1-216-295-00 SHORT (CHIP) 0
JR203 1-216-295-00 SHORT (CHIP) 0
JR301 1-216-296-00 SHORT (CHIP) 0
