4
WM-EX422
SECTION 2
GENERAL
This section is extracted from
instruction manual.
OPEN
AVLS
BATT
VOL**
FF
Y
•DIRECTION***
HOLD
MEGA BASS
x
REW
*
Supplied with the European model only.
**
There is a tactile dot beside VOL to show the direction to turn up the volume.
***
The button has a tactile dot.
i
To attach the hand strap*
3
5
