3-3. MECHANISM DECK
3
Mechanism deck
Cabinet (center) ass
y
1
Claws
2
3-2. MAIN BOARD
Cabinet (center) assy
1
Unsolder HEAD flexible board
3
Screw (1.7
×
2.5), tapping
2
Unsolder leads from moto
r
(four places)
6
MAIN board
5
4
Claws
