Sony WM-EX422 User Manual

7
WM-EX422
3-4. CASSETTE HOLDER SUB ASSY
Cassette holder sub assy
Cabinet center
3 Spring (lid up)
4 Cassette holder sub ass
y
Cabinet center
• Use caution when installing the cassette holder assy
Install the cassette holder sub assy with the spring (lid up)
as shown below in the drawing so that it fits into the holes
on the cabinet center. Once installed, fit the left and right
pieces on.
• Press on the left & right clips from the rear of the
cabinet center and remove the boss.
2
1
